3.2 PART IDENTIFICATION AND MODELS

The Tornado and Tornado RC Monitor are shown in fi gs 3.2A and 3.2B along with the names of some various parts and controls.
GREASE FITTING
FOR ELEVATION
2 1/2" NH COUPLING
WITH LOCK
©Copyright Task Force Tips, Inc. 2008-2014
ELEVATION
LOCKING
KNOB
MODEL AND SERIAL
NUMBER ON LABEL
2-1/2" NH
COUPLING
Fig. 3.2A Manual Tornado Monitor Part Identifi cation
MANUAL OVERRIDE KNOB
FOR ELEVATION
ELEVATION TRAVEL STOP
SEE SECTION 4.2
Fig. 3.2B Tornado RC Monitor Part Identifi cation
5
TILLER BAR
OUTLET
TURNING
VANE
HORIZONTAL ROTATION
LOCKING KNOB
ELECTRIC NOZZLE
CONNECTION
GREASE FITTING FOR
HORIZONTAL ROTATION
HORIZONTAL ROTATION
TRAVEL STOP
SEE SECTION 4.2
MANUAL OVERRIDE KNOB
FOR HORIZONTAL ROTATION
ELECTRICAL CONNECTOR
POWER AND
COMMUNICATION CORD
COUPLING LOCK
RELEASE PULLPIN
QUICK CONNECT INLET
(2 1/2" ANSI 150 FLANGE SHOWN)
