  • Page 1 Reference Manual PDA-300 Sifos Technologies ® PowerSync Device Analyzer PDA-300 Technical Reference Manual Version 3.6 Revised January 21, 2014 Copyright © 2014 Sifos Technologies January 21, 2014 Sifos Technologies Page...
  • Page 2 Defective Product under warranty shall be, at Sifos’ discretion, repaired or replaced or a credit issued for an amount equal to the price paid for such Product provided that: (a) such Product is returned to Sifos Technologies after first obtaining a return authorization number and shipping instructions, freight prepaid, to Sifos’...
  • Page 3: Table Of Contents

    Automated PD Testing from PDA Interactive ............... 22 4.4.1. Each Cycle Report Mode ........................22 4.4.2. Accumulate Report Mode ........................22 4.4.3. PD Under Test Description ........................24 4.4.4. PDA Interactive Results Display ......................24 January 21, 2014 Sifos Technologies Page...
  • Page 4 Keeping Power On When a Trace Stops ....................28 4.6.2. Measured Power Snapshot is Not Real Time ..................28 4.7. User-Defined Tests ......................28 PDA-300 Firmware Upgrades ..................29 PDA-300 Remote Control Interface ................31 January 21, 2014 Sifos Technologies Page...
  • Page 5: Ieee 802.3At Powered Devices

    2.7 volts, it must perform an AC Resistance measurement to resolve the PD “detection signature”. PSE’s utilize a wide variety of methods to perform Figure 1.2 PD Detection Signature January 21, 2014 Sifos Technologies Page...
  • Page 6: Pd Classification

    This in turn allows the Type-2 PD to discriminate the two-event classification so that it can draw power beyond 13 watts following power-up. In short, the two-event classification serves as a full Type-2 power “grant” from the PSE to the PD. January 21, 2014 Sifos Technologies Page...
  • Page 7: Power Application & Overload Conditions

    PD may need to wait up to tens seconds to start a link Response Response layer LLDP negotiation with the PSE and subsequently may need to wait indefinitely for a power grant from the PSE authorizing power draw in excess Figure 1.7 Type-2 PD Start-Up January 21, 2014 Sifos Technologies Page...
  • Page 8: Link Layer Discovery Protocol

    The DC MPS scheme allows for PD’s to drop below 10 mA on a periodic or intermittent basis to save power. A PD that behaves this way may operate below 10mA for up to 250msec out of every 325msec and remain powered by the DC MPS method PSE (see Figure 1.8). January 21, 2014 Sifos Technologies Page...
  • Page 9: Pda-300 Measurement And Test Capabilities

    Defined Test is to produce a PASS/FAIL indication for a particular PD type given only the tests deemed most important for that PD. As such, this feature is useful in manufacturing or field troubleshooting type applications. This topic will be addressed further in section 2.5. January 21, 2014 Sifos Technologies Page...
  • Page 10: Automated 802.3At Poe Test Suite

    Powered from I_Mark Class pulse discharge current measured 0.25 to 4.0 mA Type-2 PSE between class pulses Pclass_pd_2 Average PD power draw following the 50msec 0.12 to 25.5 W Two-Event inrush interval January 21, 2014 Sifos Technologies Page...
  • Page 11: Pd Load Monitor

    User Defined Tests enable the formation of a customized test sequence including modified test criteria that is applied within the PDA-300 instrument. The test sequence is derived from elements of the 802.3at PoE Test suite. User January 21, 2014 Sifos Technologies Page...
  • Page 12 Users are free to modify test limits in the pop-up spreadsheet report template file (pda_report.xls) if they would like the standard spreadsheet report to be applicable to particular PD characteristics. Figure 2.5 TEST-1 Screen #2 in PDA-Interactive January 21, 2014 Sifos Technologies Page...
  • Page 13: Pda-300 Technical Specifications

    23.7k to 26.3k User-Defined Mode PSE-Accept Test 19K - 26.5K Limits** PD Detection Range 1nF-50F Capacitance Accuracy + 3% + 3nF IEEE 802.3at Test Limits 0.05F- 0.12F User-Defined Mode PSE-Accept Test 0F- 0.15F Limits** January 21, 2014 Sifos Technologies Page...
  • Page 14 Max Load: 10 to Ppeak_max / Vport (mA) MPS Load: 10 to Pclass_max / Vport Average Load: 2.3 to Pclass_max/ Vport Turn-On Voltage Range 28 to 48 V Resolution 0.1 V Accuracy IEEE 802.3at Test Limits < 42 VDC January 21, 2014 Sifos Technologies Page...
  • Page 15: Physical And Environment

    NETWORK. THE PDA-300 SHOULD BE POWERED WITH THE SUPPLIED AC CORD, WHICH INCLUDES AN EARTHING CONDUCTOR. THE GROUND TERMINAL SHOULD NOT BE MODIFIED, SINCE THIS COULD RESULT IN A PRODUCT THAT IS NOT PROPERLY EARTHED. January 21, 2014 Sifos Technologies Page...
  • Page 16 Reference Manual PDA-300 January 21, 2014 Sifos Technologies Page...
  • Page 17: Pda-300 Screen Menus

    3.2) with ability to scroll through 3 pages of parameters. PDA Interactive Pop-Up Spreadsheet: Results may optionally be loaded into a pop-up spreadsheet report. This is described below in section 4.4.1. Figure 3.3 802.3at PoE Test: Stand-Alone Results Menus 3.3. January 21, 2014 Sifos Technologies Page...
  • Page 18: Pd Load Meter Menu

    PDA Interactive, and then executed from the front panel. Once a test is selected and defined for a particular PD, the test is executed from the Begin Test soft-key. Figure 3.5 User Defined Test Selection Menus January 21, 2014 Sifos Technologies Page...
  • Page 19: User-Defined Test Configuration

    115 mA and 140 mA, sample delay of 4 seconds and duration of 30 seconds following the power-up. PDA Interactive results from this specialized test sequence are shown in Figure 3.7. Figure 3.7 User-Defined Test Results in PDA Interactive for a Class 2 PD January 21, 2014 Sifos Technologies Page...
  • Page 20 Reference Manual PDA-300 January 21, 2014 Sifos Technologies Page...
  • Page 21: Pda Interactive

    The 802.3at PoE Test and User-Defined Test menus operate in the same manner as the stand-alone instrument. Set-up and operating screens appear on both the PDA Interactive window and PDA-300 display. Figure 4.2 PDA Interactive GUI January 21, 2014 Sifos Technologies Page...
  • Page 22: Automated Pd Testing From Pda Interactive

    When Accumulate mode is selected (see Figure 4.4), test results will be continuously recorded to a report file but will not be displayed when each test cycle completes. Up to 24 cycles of test result data may be accumulated. The results January 21, 2014 Sifos Technologies Page...
  • Page 23 Change Report Mode from Each Cycle to Accumulate. Change the test mode from 802.3at to Custom. Change the test mode from Custom test mode to another Custom test mode (for example, Custom Test 1 to Custom Test 2). January 21, 2014 Sifos Technologies Page...
  • Page 24: Pd Under Test Description

    If the device presents an invalid class signature as defined previously in section 1.3, the Class will be forced to 0 (zero). In this case, the diagnostic message Invalid Class Current will appear on the screen immediately below the Class January 21, 2014 Sifos Technologies Page...
  • Page 25: Ppeak_Max And Pclass_Max Limit Checking & Violation Capture

    PD will request during an LLDP dialog with the PSE. This entry is performed in the Pclass max per LLDP req box and must be completed prior to initiating the load trace. If January 21, 2014 Sifos Technologies Page...
  • Page 26: Watt∙Hour Meter

    As with the 802.3at PoE Test spreadsheet report, the Load Monitor spreadsheet must be saved to a different file name or directory path in order to preserve the test data. NOTE: The pda_lm_report.xls template file must never be overwritten. January 21, 2014 Sifos Technologies Page...
  • Page 27: Load Meter Display Is Not Real Time

    Once the trace has been stopped, the binary file will be translated into ASCII text, in a Comma Separated Value (CSV) format. The binary to text translation causes an expansion of approximately 11.8:1. For example, a 10 minute trace accumulated at 6000 bytes/minute would expand to a CSV file approximately 708 kbytes long. January 21, 2014 Sifos Technologies Page...
  • Page 28: Keeping Power On When A Trace Stops

    Test limits applied will be 802.3at PoE specifications regardless of test limits configured in the PDA-300 instrument. Users may choose to modify the pda_report.xls report template “Limits” worksheet if customized test limits are desired in the standardized spreadsheet report. January 21, 2014 Sifos Technologies Page...
  • Page 29: Pda-300 Firmware Upgrades

    5. PDA-300 Firmware Upgrades Firmware Upgrades may be offered by Sifos Technologies to provide additional functionality in the PDA-300. A firmware file is provided when an upgrade is issued. This file has a .hex extension and should be installed as follows.
  • Page 30 Reference Manual PDA-300 January 21, 2014 Sifos Technologies Page...
  • Page 31: Pda-300 Remote Control Interface

    1: 802.3at PoE Test 2: Load Meter 3: User-Defined Test 4: About >1 1: Set-up 2: - 3: Begin Test 4: Exit >3 Pass 1: - 2: Results 3: Next Test 4: Exit >2 January 21, 2014 Sifos Technologies Page...
  • Page 32 PDA-300, the instrument may stop responding to anything transmitted on the RS-232 line. The only way to recover at this point is to cycle power on the instrument. January 21, 2014 Sifos Technologies Page...
