SECTION
1. NEW FEATURES
2. GENERAL OVERVIEW
3. ANALYZER NOTES
4. GUI INSTALLATION
5. GUI CONTROLS
6. SPECTRUM ANALYZER ETHERNET SETUP
7. MANAGING SPECTRUM ANALYZER LIST PROFILES
8. GUI NETWORK
9. TERMS AND CONDITIONS
10. LIMITED WARRANTY POLICY

1. NEW FEATURES

Window Resize - The GUI can now dynamically resize to fit most monitor resolutions.
•
• Master GUI Mode - Connect and control up to 12 spectrum analyzers by going to
Configure>Miscellaneous and changing the Windows to Show value.
Data Acquisition (DAQ) - used for general data collection or for automated signal analysis
•
and email alarming if a carrier has been lost. DAQ requires more user thought and input than
the Alarm but can do much more than Alarms. The original Alarm feature only applies to a
signal that is on-screen and does not change, but DAQ allows alarming to cover the entire
spectrum range of the analyzer and any RF Inputs available. See the included DAQ.xls
spreadsheet for a template of the DAQ script. There are many cell comments that describe the
valid inputs and applications.
Avcom of Virginia - 7729 Pocoshock Way - Richmond - Virginia - 23235 - USA

TABLE OF CONTENTS

(GUI RELEASE 2.9.6 AND GREATER)
www.avcomofva.com
- PHONE 1.804.794.2500 - FAX 1.804.794.8284
- 2 -
Page
2
3
4
5
6
14
16
18
21
21
