Installation
Instructions
Questions? Call XO Appliance at 1-973-403-8900
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT –
•
instructions for local inspector's use.
IMPORTANT –
•
governing codes and ordinances.
Note to Installer –
•
instructions with the Consumer.
24 Eisenhower Parkway | Roseland, NJ 07068
p. 973.403.8900 | www.xoappliance.com
Save these
Observe all
Be sure to leave these
MODEL: XOOTR24BS
Over the Range
Microwave Oven
Note to Consumer –
•
instructions for future reference.
• Skill level – Installation of this appliance requires
basic mechanical and electrical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
KEEP THESE INSTRUCTIONS
Keep these
READ CAREFULLY
p/n A06823411
March 2020
Advertisement
Table of Contents
Related Manuals for Xo XOOTR24BS
Summary of Contents for Xo XOOTR24BS
- Page 1 Over the Range Installation Microwave Oven Instructions Questions? Call XO Appliance at 1-973-403-8900 BEFORE YOU BEGIN Note to Consumer – Read these instructions completely and carefully. • Keep these instructions for future reference. IMPORTANT – • Save these • Skill level – Installation of this appliance requires instructions for local inspector’s use.
-
Page 2: Table Of Contents
Installation Instructions Adapting Microwave Blower CONTENTS – for Outside Back Exhaust....17 18 General information Mount the Microwave Oven ....19 Important Safety Instructions ........3 Recirculating ........– Electrical Requirements .......... 3 Attach Mounting Plate to Wall .... Damage – Shipment/Installation......4 Preparation of Top Cabinet ....2 Parts Included............ -
Page 3: Important Safety Instructions
Installation Instructions IMPORTANT SAFETY INSTRUCTIONS This product requires a three-prong grounded outlet. You should have the wall receptacle and circuit checked The installer must perform a ground continuity check by a qualified electrician to make sure the receptacle is on the power outlet box before beginning the properly grounded. -
Page 4: Damage-Shipment/ Installation
Installation Instructions DAMAGE—SHIPMENT/ PARTS INCLUDED (CONT.) ADDITIONAL PARTS INSTALLATION PART QUANTITY • If the unit is damaged in shipment, return the unit to the store in which it was bought for repair Cabinet or replacement. Template • If the unit is damaged by the customer,repair or replacement is the responsibility of the customer. -
Page 5: Tools You Will Need
Installation Instructions TOOLS YOU WILL NEED Ruler or tape measure and straight edge Pencil Carpenter square # 1 Phillips screwdriver (optional) Tin snips (for cutting damper, if required) Scissors Electric drill with drill bits (to cut template) ” ” ” Filler blocks or scrap wood pieces, if needed for top cabinet spacing... -
Page 6: Placement Of The Mounting Plate
Installation Instructions PLACEMENT OF THE MOUNTING PLATE 4 Cut the middle of the outer protective plastic bag to REMOVING THE MICROWAVE r emove the ounting late OVEN FROM THE CARTON/ Screws Screws REMOVING THE MOUNTING Mounting Plate PLATE Remove the installation instructions,use and care, exhaust adapter, turntable ring, shelf, filters, glass bag. -
Page 7: Determining Wall Plate Location
Installation Instructions DETERM INING WALL PLATE LOCATION UNDER YOUR CABINET Plate position - beneath flat bottom Plate position - beneath framed cabinet bottom cabinet recessed NOTE: READ IT IS VERY IMPOR IN THE AND FOLLO TANT BEFOR INSTA LLATIO W THE DIREC REAR E PROCE... -
Page 8: Aligning The Wall Plate
Installation Instructions ALIGNING THE WALL PLATE 3/8" TO EDGE 12" Trim the rear wall template al ong the dotted line. NOTE: IT IS VERY IMPORTANT TO READ AND FOLLOW THE DIRECTIONS IN THE INSTALLATION INSTRUCTIONS BEFORE PROCEEDING WITH THIS REAR WALL TEMPLATE. This Rear Wall Template serves to position the bottom 4"... -
Page 9: Installation Types
Installation Instructions INSTALLATION TYPES (Choose A, B or C) This microwave oven is designed for adaptation to NOTE: This microwave is shipped assembled for the following three types of ventilation: Recirculating. Select the type of ventilation required for your installation and proceed to that section. - Page 10 Installation Instructions INSTALLATION INSTRUCTIONS FOR EXTERNAL EXHAUST DUCTING Maximum duct length: NOTE: If you need to install ducts, note that the total duct length of 3 ” x 10” (8.2 x 25.4 cm) rectangular or For satisfactory air movement, the total duct length of 5”...
- Page 11 24 ft (7.3 m) 24 ft or 7.3 m 1 ft (0.3 m) 12 ft or 3.6 m 5 ft (7.6 m) 5 ft or 15.2 m Equivalent lengths of duct pieces are based Total Ductwork on actual tests and reflect requirements for 41 ft or 10.4 m good venting performance with any hood.
-
Page 12: Aoutside Top Exhaust
Installation Instructions OUTSIDE TOP EXHAUST (Vertical Duct) INSTALLATION OVERVIEW A1. Attach Mounting Plate to Wall A2. Prepare Top Cabinet Adapting Microwave Blower for Outside Top Exhaust A4. Check Damper Operation Mount Microwave Oven 3/8" TO EDGE te along the dotted lin Trim the rear wal l t empla 12"... -
Page 13: Preparation Of Top Cabinet
Installation Instructions USE TOP CABINET TEMPLATE Carefully pull out the blower unit. The wires FOR PREPARATION OF TOP will extend far enough to allow you to adjust the blower unit. CABINET End B You need to drill holes for the top support screws, a hole large enough for the power cord to fit through, and a cutout large enough for the exhaust adaptor. -
Page 14: Checking For Proper Damper Operation
Installation Instructions MOUNT THE MICROWAVE ADAPTING MICROWAVE OVEN BLOWER FOR OUTSIDE TOP EXHAUST Secure blower unit to microwave with the screw removed in Step 1. Make sure the screw is tight. Replace blower plate with the screw removed in Step 1. Make sure the screw is tight. FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE RECOMMEND THATTWO PEOPLE INSTALL THIS MICROWAVE OVEN. -
Page 15: Mount The Microwave Oven
MOUNT THE MICROWAVE ADJUST THE EXHAUST OVEN (cont.) ADAPTOR Open the top cabinet and adjust the exhaust adaptor Cabinet Front to connect to the house duct. Cabinet Bottom Shelf Filler Block Back of Damper Blower Plate Microwave Equivalent to Depth of Cabinet Recess Self-Aligning Screw... -
Page 16: Boutside Back Exhaust
Installation Instructions OUTSIDE BACK EXHAUST (Horizontal Duct) INSTALLATION OVERVIEW B1. Prepare Rear Wall B2. Remove Blower Plate B3. Attach Mounting Plate to Wall B4. Prepare Top Cabinet B5. Adjust Blower B6. Mount the Microwave Oven 3/8" TO EDGE te along the dotted lin Trim the rear wal l t empla 12"... -
Page 17: Attach Mounting Plate To Wall
Installation Instructions ATTACH THE MOUNTING PLATE TO THE WALL • Read the instructions on the TOP CABINET TEMPLATE. • Tape it underneath the top cabinet. • Drill the holes, following the instructions on the Attach the plate to the wall using toggle bolts. TOP CABINET TEMPLATE. -
Page 18: Adapting Microwave Blower For Outside Back Exhaust
Installation Instructions Place the blower unit back into the opening. ADAPTING MICROWAVE BLOWER FOR OUTSIDE AFTER: Fan Blade Openings Facing Back BACK EXHAUST (cont.) End A Rotate blower unit counterclockwise 180°. Before Rotation After Rotation End B CAUTION: Do not pull or stretch the blower unit wiring. -
Page 19: Mount The Microwave Oven
Installation Instructions Cabinet Front MOUNT THE MICROWAVE Cabinet Bottom Shelf OVEN Filler Block Equivalent to Depth of Cabinet Recess Self-Aligning Screw FOR EASIER INSTALLATION AND PERSONAL Microwave Oven Top SAFETY, WE RECOMMEND THATTWO PEOPLE Attach the microwave oven to the top cabinet. INSTALL THIS MICROWAVE OVEN. -
Page 20: Recirculating
Installation Instructions RECIRCULATING (Non-Vented Ductless) INSTALLATION OVERVIEW C1. Attach Mounting Plate to Wall C2. Prepare Top Cabinet C3. Check Blower Plate 3/8" TO EDGE te along the dotted lin Trim the rear wal l t empla 12" NOTE: IT IS VERY IMPORTANT READ AND FOLLOW THE DIRECTIONS INSTRUCTIONS... -
Page 21: Check Blower Plate
Installation Instructions MOUNT THE MICROWAVE OVEN USE TOP CABINET TEMPLATE FOR PREPARATION OF TOP CABINET You need to drill holes for the top support screws and a hole large enough for the power cord to fit through. FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE RECOMMEND THATTWO PEOPLE INSTALL THIS MICROWAVE OVEN. -
Page 22: Charcoal Filter
Installation Instructions MOUNT THE MICROWAVE Open the microwave door and remove the two o l ; OVEN (cont.) microwave using a #1 Phillips screwdriver. Insert 2 self-aligning screws through outer top cabinet Charcoal holes. Turn two full turns on Filter each screw. - Page 23 Installation Instructions Press the bottom of charcoal filter to place it into the correct position. Reinstall the vent by sliding the bottom of the vent into place. Push the vent top into position and slide right into place. Replace the two vent mounting screws located on top of the microwave using a #1 Phillips screwdriver.
-
Page 24: Before You Use Your Microwave
Installation Instructions BEFORE YOU USE YOUR MICROWAVE Make sure the microwave oven has been Replace house fuse or turn breaker back on. installed according to instructions. Read the & CARE Manual. Remove all packing material from the microwave oven. Install turntable . - Page 25 PN:16170000A53735 10-23/64 10-23/64 NOT E: IT READ AND IN THE FOLLO W VER Y IMPORTA THE DIRECTIONS NT TO BEFO RE REAR WAL This R ear I NST ALLATION PROC EED L TEMPLA Wal l Temp ING WI TH INSTR U T HIS CTI ONS 3/8"...
