FEATURES
Large LCD display
Electro-Luminescent back light
Water resistant
12/24 hour format
Auto calendar (month, date,
day of week)
Functional Specifications
EL backlight
Hold S1 for 1 sec to light up, the light remains on for 5sec from the last press of any button.
Time Mode
Field 1: day of week.
Field 2: current time.
Field 3: month/day or seconds.
PRESS [S2] to toggle between month/day and seconds.
How to Set the Time
1. Hold [S3] 1 second to enter the time set mode. The "HR" digit will flash. PRESS [S2] to adjust the
hours.
2. At the desired hours, PRESS [S1] sequentially to go to setting of "MIN", "SEC", "12/24Hr", "YR",
"MTH" and "DAY" with the corresponding digits flashing.
3. Press [S2] to adjust the flashing digits.
4. At the desired date, PRESS [S3] to exit time set mode or PRESS [S1] to go through the time
setting process again (step 1-3). Time set can be completed any time by pressing [S3].
Daily Alarm Mode
It allows the user to select and enter settings for up to four alarms.
Field 1: AL1, AL2, AL3 or AL4
Field 2: alarm time.
Field 3: " ON " or " OFF "(the activation status of that alarm).
If any of the alarms is activated, a "
When the set alarm is reached, the alarm sounds for 30sec or until any button is pressed.
How to Set the Daily Alarms
1. From TIME mode PRESS [S3] to select AL1, AL2, AL3 or AL4.
2. Press [S1] to sequentially select "ON/OFF", "AL HR" and "AL MIN" with the corresponding digits
flashing, Press [S2] to set the flashing digits.
3. At the desired alarm minutes, PRESS [S1] to complete alarm time setting. PRESS [S3] again to
go to the next alarm. To activate other alarms, repeat steps 1-3 for the selected alarm (AL1, AL2,
AL3 & AL4).
DT 610 COMPASS WATCH
OPERATING INSTRUSTIONS
4 daily alarms
Stopwatch
Countdown timer
Compass
Temperature, user selectable °F
or °C
" icon is displayed in Field 1 in all modes.
S4
COMPASS
Mode Bar
Indicator
S3
RESET
SELECT
SPLIT
1
MODE
PM
TIME
COMP TEMP
CHR
TIMER
SET
START/STOP
Outer Circumference
TIME
COMP
TEMP
CHR
TIMER
S1
EL
Field 1
Field 2
Field 3
S2
