REVISION
A01
> INTRODUCTION
This procedure is intended to guide you through the process of checking the reference voltages for the
Stepper Driver controllers on the X400, also known as Pololu A4988.
> PROCEDURE
1. Determine your Stepper Motor Type
Type: MOONS Motor
2. Remove hardware from bottom blue panel of printer. Once removed, tape to the build plate
with blue painter's tape.
5246 SW 8
X400 Pololu Reference Voltage Check
DATE
02/14/17
CONFIDENTIAL & PROPRIETARY
DO NOT DISTRIBUTE
ST, STE 204-A . Coral Gables, FL. 33134 || 786.701.0700 || www.3DChimera.com
TH
DESCRIPTION
Initial Release
Type: FULLING Motor
PAGE 1 OF 3
AUTHOR
AH
Advertisement
Table of Contents
Related Manuals for 3DChimera Pololu A4988
Summary of Contents for 3DChimera Pololu A4988
- Page 1 Initial Release > INTRODUCTION This procedure is intended to guide you through the process of checking the reference voltages for the Stepper Driver controllers on the X400, also known as Pololu A4988. > PROCEDURE 1. Determine your Stepper Motor Type...
- Page 2 5. Once inside, identify the Pololu drivers. Each driver is in a labeled position, as follows: EXT1 EXT0 CONFIDENTIAL & PROPRIETARY DO NOT DISTRIBUTE PAGE 2 OF 3 5246 SW 8 ST, STE 204-A . Coral Gables, FL. 33134 || 786.701.0700 || www.3DChimera.com...
- Page 3 FULLING Motor (V) MOONS Motor (V) 0.45 0.27 0.53 0.46 0.40 EXT 0 0.45 0.45 EXT 1 0.45 0.45 CONFIDENTIAL & PROPRIETARY DO NOT DISTRIBUTE PAGE 3 OF 3 5246 SW 8 ST, STE 204-A . Coral Gables, FL. 33134 || 786.701.0700 || www.3DChimera.com...
