REVISION
A01
> INTRODUCTION
This procedure is intended to guide you through removing the Y-Axis belt. This may be necessary in the
following cases:
•
Y-Axis motor needs to be checked for function
•
Y-Axis motors needs to be replaced (i.e. broken shaft)
•
Adjustment of the pulley on the Y-Axis motor
•
Installation of the Y-Axis Upgrade Kit
•
Replacement of the Y-Axis Belt
•
Tension adjustment in the Y-Axis Belt
> PROCEDURE
1. Remove the top panel
2. Remove the side panel hex nuts & handle screws
5246 SW 8
X400 Y-AXIS BELT REMOVAL
DATE
09.18.15
CONFIDENTIAL & PROPRIETARY
DO NOT DISTRIBUTE
TH
ST, STE 204-A . Coral Gables, FL. 33134 || 786.701.0700 || www.3DChimera.com
DESCRIPTION
Initial Release
PAGE 1 OF 3
AUTHOR
AH
Advertisement
Table of Contents
Related Manuals for 3DChimera X400
Summary of Contents for 3DChimera X400
- Page 1 1. Remove the top panel 2. Remove the side panel hex nuts & handle screws CONFIDENTIAL & PROPRIETARY DO NOT DISTRIBUTE PAGE 1 OF 3 5246 SW 8 ST, STE 204-A . Coral Gables, FL. 33134 || 786.701.0700 || www.3DChimera.com...
- Page 2 4. Loosen the hex nuts on the side of the x-axis carriage to loosen the belt CONFIDENTIAL & PROPRIETARY DO NOT DISTRIBUTE PAGE 2 OF 3 5246 SW 8 ST, STE 204-A . Coral Gables, FL. 33134 || 786.701.0700 || www.3DChimera.com...
- Page 3 5. Manipulate the belt over the y-axis pulley on the motor CONFIDENTIAL & PROPRIETARY DO NOT DISTRIBUTE PAGE 3 OF 3 5246 SW 8 ST, STE 204-A . Coral Gables, FL. 33134 || 786.701.0700 || www.3DChimera.com...
