Anvil FTA0400 R01 Installation Operation And Care

Flat top griller electric

Advertisement

Quick Links

LIMITED WARRANTY
All equipment which is sold under ANVIL trademark and used for
commercial purposes is warranted against defects in materials and
workmanship. The warranty runs for one year from the date of origi-
nal installation and is for the benefit of the original purchaser only.
All other Warranties ,expressed or implied , statutory or otherwise,
including without limitations any implied Warranty of Merchantability
or fitness for purpose are excluded .The Seller shall in no event be
liable for direct,indirect or consequential damages in connection with
ANVIL commercial products.
The Sellers obligation under this Warranty is limited to the re-
pair of defects without charge. Defective units must be taken or
shipped,transportation charges prepaid,to ANVIL.
This Warranty is not effective if damage occurs because of
accident,carelessness,improper installation,lack of proper set-
up,supervision when required or if the equipment is installed or
operated in any manner contrary to the installation and operating
instructions. In these cases,repairs will be made at a reasonable
cost. Work performed by unauthorized personnel or unauthorized
service agencies using non Anvil spares voids this Warranty.
NB:
REGISTER ON-LINE TODAY
Register your warranty on-line now at www.anvilworld.com
NO WEB ACCESS
If you do not have access to the web. Kindly register by completing
the warranty registration form and fax it to the anvil office in the
country of purchase.
Failure to do so will invalidate your warranty.
4-INS-FTA0400R01
FLAT TOP GRILLER ELECTRIC
INSTALLATION OPERATION AND CARE OF
FLAT TOP GRILLER ELECTRIC
MODELS: FTA0400 R01/FTA0400-120 R01/FTA3400 R01
FTA4400 R01/FTA4400-120 R01/FTA2600 R01
FTA0600 R01/FTA1600 R01/FTA3600 R01
FTA0900 R01/FTA4600 R01

Advertisement

loading

Summary of Contents for Anvil FTA0400 R01

  • Page 1 NO WEB ACCESS If you do not have access to the web. Kindly register by completing the warranty registration form and fax it to the anvil office in the country of purchase. Failure to do so will invalidate your warranty.
  • Page 2 Allow the griller to burn in for +/-30 minutes. You will notice smoke appearing due to the protective coatings burning in. This is normal. ANVIL AXIS LOGO ELEMENT CLAMP BAR After the burning in period has lapsed, turn the temperature con- PROBE CLAMP trol knob down to the desired operating temperature.
  • Page 3 EXPLODED DIAGRAM SPECIFIC INSTALLATION AND OPERATION INSTRUCTIONS FLAT TOP GRILLER 6kW 2 PHASE FTA4600 R01 FTA 1600 – Egg and Bacon Griller The griddle plate surface is divided into two halves, a flat half that can be thermostatically controlled to 300ºC (570ºF) and the other half, which is a tank, constructed onto the griddle surface.
  • Page 4 THERMOSTAT 2. The 900mm griller (FTA 0900) is equipped with three thermostats. ANVIL AXIS LOGO For accurate temperature control of the three heating zones, whilst the 600mm griller (FTA 4600) is fitted with two thermostats for the ELEMENT CLAMPING BRACKET independent control of the two heating zones.
  • Page 5 EXPLODED DIAGRAM 400mm EGG FRYER 2kW WARNING FTA4400 R02 Burn Hazard. Do not touch hot food,liquid or heating surfaces while equipment is heating or operating Hot surfaces and food can burn skin. Allow the hot surfaces to cool before handling CLEANING 1.
  • Page 6 THERMOSTAT READ ALL INSTRUCTIONS BEFORE USE. FAILURE TO FAT CUP TRAY FOLLOW THESE PRECAUTIONS COULD RESULT IN INJURY TO ANVIL AXIS LOGO YOURSELF AND OTHERS ELEMENT CLAMP BAR When this appliances is to be positioned in close proximity THERMOSTAT HOLDING CLIP to a wall, partitions, kitchen furniture, decorative finishes, etc.
  • Page 7 EXPLODED DIAGRAM POSITIONING DIAGRAM FLAT TOP ELECTRIC GRILLER HALF RIBBED FLAT TOP EGG GRILLER ELECTRIC FTA2600 R01 FTA0400 R01/FTA1400 R01/FTA2400 R01 FTA4400 R02...
  • Page 8 BEZEL KNOB CONTROL PANEL INSERT BEZEL EGG GRILL CONTROL THERMOSTAT BACON GRILL CONTROL THERMOSTAT GRILLER FAT TRAY ANVIL AXIS LOGO THERMOSTAT BULB CLAMPING PAD ELEMENT CLAMPING BRACKET ELECTRICAL COVER GALVANISED BOTTOM COVER GRILLER ELEMENT COVER ELEMENT 1500W ADJUSTABLE PLASTIC FEET...
  • Page 9 EXPLODED DIAGRAM POSITIONING DIAGRAM FLAT TOP EGG AND BACON GRILLER FLAT TOP EGG AND BACON GRILLER FTA1600 R01 FTA1600 R01...
  • Page 10 STAINLESS STEEL BODY CONTROL FACIA PANEL PILOT LIGHT BEZEL THERMOSTAT KNOB CONTROL PANEL INSERT THERMOSTAT GRILLER FAT TRAY ELEMENT INSULATION ELEMENT COVER ANVIL AXIS LOGO GALVANIZED BOTTOM COVER GALVANIZED ELEMENT COVER ADJUSTABLE FEET 3 PHASE CONNECTOR BLOCK 900 GRIDDLE TOP ASSEMBLY...
  • Page 11: Electrical Connection Information

    ELECTRICAL CONNECTION INFORMATION EXPLODED DIAGRAM FLAT TOP ELECTRIC GRILLER 2 PHASE FTA0900 R01 IT IS ESSENTIAL TO MAKE SURE THAT THE INCOM- ING VOLTAGE IS THE SAME AS THE RATED VOLTAGE OF THE OF THE UNIT AS FOUND ON THE SERIAL PLATE.
  • Page 12 GRILLER ELEMENT 2000W/230V 1-2000W-M/GRILL BODY ASSEMBLY CONTROL PILOT LIGHT 1-PL-BMA0001 CONTROL PANEL FACIA WIRING DIAGRAM PILOT LIGHT FLAT TOP GRILLER BEZEL FTA0400 R01 -120V THERMOSTAT KNOB CONTROL PANEL INSERT LEGEND DESCRIPTION PART NUMBER FAT TRAY SHIELD CONTROL THERMOSTAT 1-EGO-150 ANVIL AXIS LOGO...
  • Page 13 EXPLODED DIAGRAM WIRING DIAGRAM FLAT TOP ELECTRIC GRILLER FLAT TOP GRILLER FTA0600 R02 FTA3400 R01 LEGEND DESCRIPTION PART NUMBER CONTROL THERMOSTAT 1-EGO-150 GRILLER ELEMENT 2800W/230V 1-2800W-GRILL CONTROL PILOT LIGHT 1-PL-BMA0001 WIRING DIAGRAM 400MM EGG FRYER FTA4400 R02/FTA4400-120 R02 LEGEND DESCRIPTION FTA4400 FTA4400-120 CONTROL THERMOSTAT...
  • Page 14 PILOT LIGHT 230V CONTROL KNOB BEZEL MODEL: FLAT TOP GRILLER - 230V FACIA PANEL INSERT GRILLER THERMOSTAT MODEL CODE: FTA0600/ FTA2600 / FTA3600 ANVIL AXIS LOGO GRILLER FAT TRAY ELEMENT CLAMP BAR PROBE CLAMP DESCRIPTION LEGEND PART NUMB GALVANIZED BOTTOM COVER...
  • Page 15: Exploded Diagram

    EXPLODED DIAGRAM WIRING DIAGRAM 40mm FLAT TOP ELECTRIC GRILLER FLAT TOP GRILLER 6kW 2 PHASE FTA0400 R01 FTA4600 R01 LEGEND DESCRIPTION PART NUMBER THERMOSTAT FOR CIRCUIT 1 1-EGO-150 THERMOSTAT FOR CIRCUIT 2 1-EGO-150 ELEMENT FOR CIRCUIT 1 2800W/230V 5-2800W-GRILL ELEMENT FOR CIRCUIT 2 2000W/230V...
  • Page 16 WIRING DIAGRAM WIRING DIAGRAM FLAT TOP GRILLER BACON AND EGG FLAT TOP GRILLER FTA1600 R01 FTA0900 R01 LEGEND DESCRIPTION PART NUMBER LEGEND DESCRIPTION PART NUMBER CONTROL THERMOSTAT 1-THERM-FF-UL CONTROL THERMOSTAT FOR CIRCUIT 1 1-EGO-150 CONTROL THERMOSTAT 1-EGO-150 CONTROL THERMOSTAT FOR CIRCUIT 2 1-EGO-150 GRILLER ELEMENT 1500W/230V 5-1500W-GRILLER...
