Grizzly T27708 Instructions Manual

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Specifications
Cart Size (L x W x H) ................... 44" x 33" x 11"
Overall Size (L x W x H) .............. 62" x 33" x 25"
Wheel Size (H x W) ................................. 13" x 4"
Total Load Capacity .................................250 lbs.
Tire Pressure ............................................ 25 PSI
Net Weight ................................................ 44 lbs.
Inventory (Figures 1–2)
A. Dump Bucket .............................................. 1
B. Wheels ....................................................... 2
C. Axle Supports ............................................. 2
D. Tongue ....................................................... 1
E. Axle ............................................................ 1
F. Support Plate .............................................. 1
G. Bracket ....................................................... 1
H. Dump-Release Lever ................................. 1
I. Support Brace ............................................ 1
J. Hitch Pin ..................................................... 1
K. Hex Bolts M8-1.25 x 20 .............................. 2
L.
Lock Nuts M8-1.25 ..................................... 2
M. Hex Bolt M6-1 x 90 .................................... 1
N. Spacers 8 x 34mm ..................................... 2
O. Lock Nut M6-1 ............................................ 1
P. Extension Spring 2 x 14 x 113mm ............. 1
Q. Phillips Head Screws M6-1 x 16 ................ 4
R. Phillips Head Screws M6-1 x 20 ................ 4
S. Lock Washers 6mm ................................... 8
T.
Hex Nuts M6-1 ........................................... 8
U. Phillips Head Screws M8-1.25 x 16 ........... 8
V. Lock Washers 8mm ................................. 10
W. Hex Nuts M8-1.25 ...................................... 8
X. Flat Washers 17mm ................................... 4
Y. Cotter Pins .................................................. 4
If any nonproprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store. If you need
help with your new item, call our Tech Support at:
(570) 546-9663.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © MAY, 2016 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 04/16) #WK18158 PRINTED IN CHINA
MODEL T27708
250 lb. POLY DUMP CART
Qty
A
D
E
U
V
W
INSTRUCTIONS
SUFFOCATION HAZARD!
Immediately discard all plas-
tic bags and packing materi-
als to eliminate choking/suf-
focation hazards for children
and animals.
F
Figure 1 Large item inventory.
.
K
L
J
Q
S
X
Figure 2 Small item inventory.
.
B
C
G
I
H
M
N
O
R
P
T
Y
