TECHNICAL MANUAL
VRF INVERTER MULTI-SYSTEM AIR-CONDITIONERS
(INDOOR UNIT)
KXZ series
Ceiling cassette - 4 way compact type
FDTC15KXZE1
FDTC22KXZE1
FDTC28KXZE1
FDTC36KXZE1
FDTC45KXZE1
FDTC56KXZE1
Note:
•
(1) Regarding the outdoor unit KXZ series, refer to the No.'14
No.'17
KX-T-265.
•
Manual No.'18•KX-T-281
updated December 14, 2018
KX-T-223, No.'15
KX-T-227 and
•
•
