Pairing Transceivers; Unpairing Transceivers - iO HVAC Controls iO-WR Installation & Operation Manual

TYPICAL WIRING FOR
BUTTON
LED

Pairing Transceivers

Since the transceivers have been paired at the factory, it is highly unlikely that
they will require re-pairing. However, it may be necessary in the event one of the
transceivers requires replacement.
1. After all wiring is performed, apply 24
transceivers.
2. The base transceiver
times per second. When in this mode, the base will broadcast a pair request
message once every 5 seconds until it receives a pair response from the satellite
transceiver.
3. The satellite LED
pushbutton on the satellite transceiver until it starts flashing red and green every
3 seconds. Once this pattern appears on the
4. Pairing is confirmed when both transceiver
the transceivers will poll each other every 15 seconds regardless whether any
digital input signals are activated. The
message is received and go solid red when a data message is sent.
Note: When using multiple iO-
only power up one base and one satellite to be paired at a time.

Unpairing Transceivers

Unpairing a base and satellite transceiver is accomplished by holding down the
button while applying 24
seconds. While the button is held down, the
green 5 times per second. Once the unpairing process is complete, the
flash as described in the pairing section. If the button is released prior to the
completion of the unpairing process, the transceivers will transition to the paired
mode, retaining their previous paired status.
LED will flash between red and green at a rate of 3
will flash red every 3 seconds. Press and hold down the
WR -401 wireless relays in the same location,
VAC and continuing to hold the button down for about 5
3 HEAT / 2 COOL HEAT PUMP
TRANSCEIVER MODULE
TERMINAL DESIGNATIONS
C = 24VAC COMMON
R = 24VAC HOT
W = AUXILIARY HEAT SEND
O/B = REVERSING VALVE REC
Y2 = SECOND STAGE COMPRESSOR REC
Y1 = FIRST STAGE COMPRESSOR REC
A separate transformer may
be required if 24
available from the indoor unit
VAC to both the base and satellite
LED , release the pushbutton.
LED s go solid green. Once paired,
LED s will flash red rapidly when a data
LED will flash between red and
iO-WRSM
SATELLITE
(
(
VAC is not
C
R
O/B
Y2
Y1
W
)
)
( )
( )
LED will
