- Page 1 BRD 2000/2080 For use under U.S. Patent numbers 6159132, D459773, D438264 * This item is for consumer use only and it is not meant for commercial use. OWN ER’ S MA NUAL...
- Page 2 5. ALWAYS use your Equipment in a warm, dry, level well-lit and ventilated 11. NEVER use the Equipment if it does indoor area. not function properly. 6. ALWAYS keep body and clothing free and clear of all moving parts. BRD 2000/2080 Page 1...
-
Page 3: General Information
General Information Safety Storage and Use Before you undertake any exercise program, Your product is intended for use in clean please be sure to consult with your doctor. dry conditions. You should avoid storage in Frequent strenuous exercise should be excessively cold or damp places as this may approved by your doctor and proper use lead to corrosion and other related problems. - Page 4 (M12x24 mm) [1 Piece] [8 Pieces] [2 Pieces] [3 Pieces] Pre-assembled Tools #69 Tool 2 (S8) #85 Tool 4 (S6) [1 Piece] [1 Piece] #70 Tool 3 (S13-14-15) #68 Tool 1 (2-S17,S19) [1 Piece] [2 Pieces] BRD 2000/2080 Page 3...
-
Page 5: Parts Listing
Friction Belt (1150L mm) Seat Post Washer (φ10.5x2xφ20 mm) Tension Adjustment Knob Tool 4 (S6) Square Inner Plug (口30 mm) Wavy Washer (16.2xφ21x17x0.3t mm) Screw (ST4.8x20 mm) Wavy Washer Screw (ST4.8x40 mm) Screw (ST4.8x16 mm) Cap (S13) BRD 2000/2080 Page 4... -
Page 6: Exploded Diagram
Please continue to the next page to begin the assembly process and use this page only as a reference guide for parts and hardware. BRD 2000/2080 Page 5... - Page 7 Nuts (#47). Note: Please note that the Front Stabilizer (#02) has Front Rollers (#18) that spin for ease of relocating the unit. #47 Nut (M10) [4 Pieces] Tools #68 Tool 1 (2-S17,S19) [1 Piece] BRD 2000/2080 Page 6...
- Page 8 Make sure Left /Right Coupler Bar (04L/04R) are placed on the correct side when its horizontal Pivot Tube (which is welded at the top) faces the REAR of the machine as seen from the user . BRD 2000/2080 Page 7...
-
Page 9: Important Note
Pedal Connection Joint (#66A) and the Crankshaft (#27). If the Right/ Left Pedal Hinge Bolt (#162/163) are RIGHT Side connected to the Crankshaft (#27) incorrectly, damage to the Right/ Left Pedal Hinge Bolt (#162/163) and Crankshaft (#27) will occur. BRD 2000/2080 Page 8... - Page 10 #48 Left Nylon Nut (B0.5x20 S19) (with BLACK inner nylon wing) [1 Piece] #49 Right Nylon Nut (B0.5x20 S19) (with WHITE inner nylon ring) [1 Piece] Others #42 Cap (S17) [6 Pieces] Tools #68 Tool 1 (2-S17,S19) #69 Tool 2 (S8) [1 Piece] [1 Piece] BRD 2000/2080 Page 9...
- Page 11 #44 Hex Bolt (M10x45 mm) [4 Pieces] Repeat this process on the other side using the other Pedal (#11) onto the Left Pedal Tube (#06L). #45 Nylon Nut (M10) [4 Pieces] Tools #68 Tool 1 (2-S17,S19) [1 Piece] RIGHT SIDE BRD 2000/2080 Page 10...
- Page 12 You may adjust the Seat Post (#83) to the height most comfortable for you after complete assembly. Please always check to ensure a hole has been fully engaged when you secure and tighten the Knob Bolt (#57). BRD 2000/2080 Page 11...
- Page 13 (#07R), Right Coupler Bar (#04R), and one Knob Bolt (#17) If you encounter too much friction, try using WD40 #17 Knob Bolt (M8x36 mm) [2 Pieces] or Vaseline as a lubricant. #42 WASHER FOR M10 BOLT,T2.0 1PC #42 WASHER FOR M10 BOLT,T2.0 1PC BRD 2000/2080 Page 12...
- Page 14 Secure them together using an Arc Washer (#74) and one Nut (#75). #75 Nut (M8) [1 Piece] Tools #42 WASHER FOR M10 BOLT,T2.0 1PC #70 Tool 3 (S13-14-15) #85 Tool 4 (S6) [1 Piece] [1 Piece] #42 WASHER FOR M10 BOLT,T2.0 1PC BRD 2000/2080 Page 13...
- Page 15 ASSEMBLY IS NOW COMPLETE. HOWEVER, PLEASE READ ALL SAFETY GUIDELINES & WARNING LABELS BEFORE USING THE UNIT TO AVOID SERIOUS INJURY. #42 WASHER FOR M10 BOLT,T2.0 1PC #42 WASHER FOR M10 BOLT,T2.0 1PC #42 WASHER FOR M10 BOLT,T2.0 1PC BRD 2000/2080 Page 14...
- Page 16 “test” when you gently tug on Friction Belt (#35) away from flywheel) 1-inch NOTE: In order to clearly show parts used in Tension Adjustment process, this drawing has been modified and does not show all parts nor full assembly. BRD 2000/2080 Page 15...
-
Page 17: Safety And Maintenance
(909) 598-9876, or mail in a written request to: Body Flex Sports, Inc. 21717 Ferrero Parkway, Walnut, CA 91789. More detailed information about how to reach our CUSTOMER SUPPORT may be found on Page 1 of the Owner’s Manual under the “CUSTOMER SUPPORT” section. BRD 2000/2080 Page 16... -
Page 18: Computer Operation
Calories: Displays the amount of calories burned. Scan: Automatically alternate between the different functions. (Time, Distance, Calories) 4.BATTERY: This monitor requires one (or two) "AA" Battery(ies) depending on the model. You can replace the battery from the back of the unit. BRD 2000/2080 Page 17... - Page 19 1. Lie on your back and raise your right leg as you clasp both hands under the back of the knee. Keep your left leg straight. 2. Gently pull your right leg toward your trunk without raising your upper body. Switch leg positions and repeat. BRD 2000/2080 Page 18...
- Page 20 Switch leg positions Reverse arm positions and and repeat. repeat. BRD 2000/2080 Page 19...
-
Page 21: Proof Of Purchase
Proof of purchase Model Number BRD 2000 / BRD2080 version: 04-25-2018 BRD 2000/2080... - Page 22 This page intentionally left blank...
- Page 23 This page intentionally left blank...
- Page 24 Body Flex Sports, Inc. • 21717 Ferrero Parkway, Walnut, CA 91789 • Telephone: (888) 266 - 6789 • Email: info@bodyflexsports.com Made in China...
