INSTALLATION AND OPERATION GUIDE FOR
For all models tested through OMNI-Test Laboratories, Inc., to
ANSI Z21.60-2003/CGA 2.26-2003, Decorative Appliance for Installation in Solid-Fuel Burning
Fireplaces. For model number and O-TL seal refer to attached nameplate.
Installation and service must be provided by a qualified installer,
ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY
NOTE:
READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING
INSTALLER: LEAVE THESE INSTRUCTIONS WITH CONSUMER!
Hargrove gas logs are made using refractory materials to create the ceramic logs. Each log is hand-finished to
assure the most realistic, detailed log available. The gas log burner system is designed to burn like wood, with
a smoky flame. For this reason, the gas log set must be burned only in a fully vented, non-combustible
fireplace with the damper completely open (In the Commonwealth of Massachusetts the damper must
either be welded in the fully open position or completely removed) and the chimney free of any
obstructions or restrictions. The fireplace must be designed and approved to burn wood.
f i r e - p a r t s . c o m
The realistic yellow flame produces carbon monoxide and soot. Under normal conditions, these products are
exhausted up the chimney. If fumes or soot, from the gas burning, are evident in the room when the damper is
fully open it indicates that the fireplace draft is defective. Do not operate your gas log set until the fireplace draft
is corrected.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
1. Do not try to light any appliance.
2. Do not touch any electrical switch; do
not use the phone in your building.
3. Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
4. If you cannot reach your gas supplier,
call the fire department.
WARNING:
If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
HARGROVE GAS LOGS
System 4 LP
service agency or the gas supplier.
It is the homeowner's responsibility to assure
their fireplace has adequate draft
RECOMMENDED BURN –IN PERIOD
Hargrove gas logs are made of special
refractory materials, which withstand high
temperatures.
One characteristic of this
material is retention of moisture.
reason, we recommend burning the logs for
only fifteen minutes during the first burning.
After allowing the logs to cool for at least one
hour, the set can be burned for any length of
time.
Hargrove gas logs carry a limited lifetime
warranty against breakage in the original
fireplace. Warranty does not include labor.
This warranty is void if excessive handling
after burning causes breakage. All
accessories and metal parts carry a two year
limited warranty in the original fireplace.
Items will be replaced during this period for
the cost of shipping.
For this
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the System 4 LP and is the answer not in the manual?

Questions and answers

Summary of Contents for O-TL System 4 LP

  • Page 1 For all models tested through OMNI-Test Laboratories, Inc., to ANSI Z21.60-2003/CGA 2.26-2003, Decorative Appliance for Installation in Solid-Fuel Burning Fireplaces. For model number and O-TL seal refer to attached nameplate. Installation and service must be provided by a qualified installer, service agency or the gas supplier.
  • Page 2 IMPORTANT INFORMATION WARNING: This appliance assembly contains burner orifices specifically for the input gas and Btu rating. Modifying or failure to use the factory orifice may cause property damage, personal injury or loss of life. 1. Do not use a natural gas set for propane or a propane set for natural gas. 2.
  • Page 3 FIREPLACE SIZES Each gas log set requires a minimum 16-inch front opening height and minimum 16-inch depth. To determine the largest set that will fit in a fireplace, the width at the center of the fireplace is the critical dimension. Table I below indicates the minimum center width for each size set. Front Width Center Width Back Width...
  • Page 4 INSTALLING SANTA FE COLLECTION GAS LOGS PARTS LIST ITEM DESCRIPTION 18CPSF(1B.1H)5 24CPSF(1B,1H)5 30CPSF(1B,1H)5 1. Pedestal Grate PG-16 5/8 PG-20 5/8 PG-25 5/8 2. System 4 Burner SF-14 SF-18 SF-22 3. Embers 4. Aluminum Connector AC-18 AC-18 AC-18 5. Concentric Pilot Control 6.
  • Page 5 DAMPER STOP Attach the damper stop clamp to the fireplace damper blade. Position the clamp to prevent full closure of the fireplace damper blade. See Figure 1 If the damper stop provided does not fit, the installer shall Fig 1 install a permanent damper stop that will keep the damper open to a minimum of opening as determined in Table II.

  • Page 6: For Your Safety

    BURNER PAN MEDIA (Fig 4) Fig 4 1. Cover the ported area of the System 4 Burner with Embers (Rockwool). Burner Ports Fire Embers 2. Light the gas and observe the flame for even distribution. 3. Most of the ember material should glow from the flame contact.

  • Page 7: For Your Safety Read Before Lighting

    FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must C. Use only your hand to push in or be lit by hand.

  • Page 8: Basic Operation

    LATCHTAP OPERATION INSTRUCTIONS FOR YOUR SAFETY WARNING: If you do not follow these instructions exactly, a fire or explosion may occur resulting in property damage, personal injury, or loss THIS APPLIANCE HAS A PILOT, WHICH MUST BE LIT BY HAND. WHEN LIGHTING THE PILOT, FOLLOW THESE INSTRUCTIONS EXACTLY.

  • Page 9: Limited Warranty

    LIMITED WARRANTY Refractory Logs Hargrove gas logs carry a limited lifetime warranty against any manufactured defect or breakage. This warranty does not cover breakage caused by excessive handling once installed and fired. Contact Customer Service for warranty claim details. Burner & Grate If the burner or grate fails due to deterioration within 2 years of the verified purchase date, contact Customer Service for warranty claim details.
