hepco & becker 6616501 01 01 Manual

Easyrack, alurack for bmw g 310 r

Advertisement

Easyrack
Artikel Nr.: / Item-no.:
6501
661
01 01
BMW G 310 R
ab Baujahr 2016 / from date of manufacture 2016
INHALT
CONTENTS
1x
700009679 Rohradapter links
1x
700009680 Rohradapter rechts
Bei Bestellung eines Aluracks zusätzlich:
1
799.901HB Alu-Rack
1
799.902HB TC-Bügel für Alu-Rack
1
799.903HB Abdeckplatte für Rack
Bei Bestellung eines Easyracks zusätzlich:
1
700008650 Easyrack
1
700008647 Abdeckblende links
1
700008648 Abdeckblende rechts
1x
700009704 Schraubensatz:
4x
Zylinderschraube ISK M8x70
4x
Zylinderschraube ISK M6x12
4x
Zylinderschraube ISK M6x20
4x
U-Scheiben ø6,4
4x
U-Scheiben ø8,4
4x
selbstsichernde Muttern M6
2x
Aludistanz Ø18xØ9x25mm
2x
Aludistanz Ø18xØ9x30mm
4x
special washer 20x20x ø6,4
Easyrack
Alurack
Artikel Nr.: / Item-no.:
652
schwarz/black
6501
01 01
schwarz/black
1x
1x
When ordering a Alurack:
1
1
1
When ordering a Easyrack:
1
1
1
1x
Alurack
700009679 tube adapter left
700009680 tube adapter right
799.901HB alu-rack
799.902HB bow for Alu-rack
799.903HB plastic cover for rack
700008650 Easyrack
700008647 plastic cover left
700008648 plastic cover right
700009704 Screw kit:
4x
allen screw M8x70
4x
allen screw M6x12
4x
allen screw M6x20
4x
washer ø6,4
4x
washer ø8,4
4x
self lock nut M6
2x
alu spacer Ø18xØ9x25mm
2x
alu spacer Ø18xØ9x30mm
4x
special washer 20x20x ø6,4
1
