- Page 1 MS993800TX “Lyndon” TV/Media Stand Artificial Zebra Wood Finish And Black Base Assembly Instructions Page 1...
- Page 2 “Lyndon” TV/Media Stand Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 3 “Lyndon” TV/Media Stand Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 4 “Lyndon” TV/Media Stand Assembly Instructions Insert 4 pcs bolts (E) through 4pcs flat washers (F) to connect support feet (2) to bottom panel (1). Tighten screws (E) with philips screwdriver. Tighten middle support foot (3) into bottom panel (1). Figure 1 Insert 8 pcs cam locks (C) into holes on fixed shelf (6) and fixed shelf (7).
- Page 5 “Lyndon” TV/Media Stand Assembly Instructions Insert 8 pcs cam locks (C) into holes on assembled unit and two side panels (8) and (9). Screw 8 pcs cam bolts (B) into holes on bottom panel (1). Attach assembled unit to bottom...
- Page 6 “Lyndon” TV/Media Stand Assembly Instructions Insert upper back panel (14) and lower back panel (15) into grooves of assembled unit’s back and attach using screws (G). Tighten screws (G) with phillips screwdriver. (10) (14) (15) Figure 5 Use screws (L) to connect hinges (K) to doors (12) and (13).
- Page 7 “Lyndon” TV/Media Stand Assembly Instructions Use screws (L) to connect left door (12) and right You may need to adjust the door by tightening door (13) to left side panel (8) and right side or loosening the two screw on the hinge in order panel (9).
- Page 8 “Lyndon” TV/Media Stand Assembly Instructions Insert drawer into assembled unit as shown in figure 9. Now your new TV/media stand is ready to use. Figure 9 Page 8...
- Page 9 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 10 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: MS993800TX “Lyndon” TV/Media Stand Southern Enterprises, Inc 600 Freeport Parkway, Suite 200 Coppell, Texas, 75019...
