- Page 1 MS994300TX “Park Lane” TV/Media Stand -Black Body with Brown Mahogany Doors/Drawers Assembly Instructions Page 1...
- Page 2 “Park Lane” TV/Media Stand Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 3 “Park Lane” TV/Media Stand Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 4 “Park Lane” TV/Media Stand Assembly Instructions Tighten 4 pcs support feet (2) and 1pc middle support foot (3) into bottom panel (1). Figure 1 Insert 8pcs cam locks (C) into holes on fixed shelf (6) and fixed shelf (7). Screw 8 pcs cam bolts (B) into holes on left middle panel (4) and right middle panel (5).
- Page 5 “Park Lane” TV/Media Stand Assembly Instructions Attach assembled unit to bottom panel (1) by inserting wood dowels into corresponding holes until assembled unit and bottom panel (1) meet. Use 4pcs bolts (N) to connect assembled unit to bottom panel (1).
- Page 6 “Park Lane” TV/Media Stand Assembly Instructions Use 11 pcs bolts (D) to connect assembled unit to top panel (10). Tighten bolts (D) with Phillips screwdriver. (10) (11) Figure 5 Insert upper back panel (14) and lower back panel (15) into grooves on the back of assembled unit.
- Page 7 “Park Lane” TV/Media Stand Assembly Instructions Use screws (G) to connect hinges (F) to doors (12) and (13). Tighten screws (G) with Phillips screwdriver. Use bolts (L) to connect handles (K) to doors (12) and (13). Tighten bolts for handle (L) with Phillips screwdriver.
- Page 8 “Park Lane” TV/Media Stand Assembly Instructions Insert nuts (H) into predrilled holes on drawer face panel (17). Attach drawer side panels (18) and (19) to drawer face panel (17) with bolts (I). Tighten bolts (I) with Phillips screwdriver. (19) (20)
- Page 9 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 10 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: MS993300TX Model: MS994300TX “Louvered-Door” TV/Media Stand “Park Lane” TV/Media Stand Model: MS994300TX Southern Enterprises, Inc “Park Lane” TV/Media Stand 600 Freeport Parkway,...
