DATA mode, GPRS ( 3Rx, 2 Tx ) CLASS 12
GSM 850
GSM 900
DCS1800
PCS1900
EDGE Data
DATA mode, EDGE( 1 Rx,4 Tx ) CLASS 12
GSM 850
GSM 900
DCS1800
PCS1900
DATA mode, EDGE( 3Rx, 2 Tx ) CLASS 12
GSM 850
GSM 900
DCS1800
PCS1900
UMTS Sleep/Idle Mode (with USB suspended)
WCDMA supply current
UMTS Talk
WCDMA 2100
WCDMA 1900
WCDMA 850
WCDMA 900
HSDPA Data
WCDMA 2100
WCDMA 1900
WCDMA 850
WCDMA 900
Note: In above table the current consumption value is the typical one of the module tested in laboratory. In
the mass production stage, there may be differences among each individual.

5.6. Electro-Static Discharge

SIM5360-PCIE is an ESD sensitive component, so more attention should be paid to the procedure of handling and
packaging. The ESD test results are shown in the following table.
SIM5360-PCIE_Hardware_Design
@power level #5 <460mA,Typical 360mA
@power level #5 <440mA,Typical 325mA
@power level #0 <400mA,Typical 285mA
@power level #0 <300mA,Typical 295mA
@power level #8 <500mA,Typical 370mA
@power level #8 <500mA,Typical 365mA
@power level #2 <450mA,Typical 350mA
@power level #2 <450mA,Typical 350mA
@power level #8 <330mA,Typical 250mA
@power level #8 <330mA,Typical 250mA
@power level #2 <300mA,Typical 225mA
@power level #2 <300mA,Typical 225mA
Sleep mode @DRX=9 1.8 mA
Sleep mode @DRX=8 2.3 mA
Sleep mode @DRX=6 3.6 mA
Idle mode @DRX=6 32 mA
@Power 23dBm Typical 460 mA
@Power 21dBm Typical 410 mA
@Power 10dBm Typical 245 mA
@Power 23dBm Typical 460 mA
@Power 21dBm Typical 440 mA
@Power 10dBm Typical 280 mA
@Power 23dBm Typical 440 mA
@Power 21dBm Typical 400 mA
@Power 10dBm Typical 250 mA
@Power 23dBm Typical 400 mA
@Power 21dBm Typical 355 mA
@Power 10dBm Typical 230 mA
@Power 23dBm CQI=22 Typical 520 mA
@Power 23dBm CQI=22 Typical 510 mA
@Power 23dBm CQI=22 Typical 460 mA
@Power 23dBm CQI=22 Typical 450 mA
