Summary of Contents for SimTech SIMCom SIM5360-PCIE Series

  • Page 1 SIM5360-PCIE_Hardware Design_V1.03...
  • Page 2 Smart Machine Smart Decision SIM5360-PCIE Hardware Design Document Title 1.03 Version 2015-01-22 Date Release Status Document SIM5360-PCIE_Hardware_Design_V1.03 Control ID General Notes SIMCom offers this information as a service to its customers, to support application and engineering efforts that use the products designed by SIMCom. The information provided is based upon requirements specifically provided to SIMCom by the customers.

  • Page 3: Table Of Contents

    Smart Machine Smart Decision Contents Version History ................................ 6 Introduction ..............................7 SIM5360-PCIE Overview ..........................8 2.1. SIM5360-PCIE Key Features ........................9 2.2. Operating Mode............................11 2.3. Functional Diagram ..........................11 Package Information........................... 13 3.1. Pin Out Diagram............................. 13 3.2. PCI Express Mini Card Connector Pin Description ................14 3.3.
  • Page 4 Smart Machine Smart Decision Table Index TABLE 1: SIM5360-PCIE SERIES FREQUENCY BANDS .................... 8 TABLE 2: SIM5360-PCIE KEY FEATURES ........................9 TABLE 3: CODING SCHEMES AND MAXIMUM NET DATA RATES OVER AIR INTERFACE ......9 TABLE 4: OPERATING MODE............................11 TABLE 5: PCI EXPRESS MINI CARD CONNECTOR PIN DESCRIPTION...............
  • Page 5 Smart Machine Smart Decision Figure Index FIGURE 1: SIM5360-PCIE FUNCTIONAL DIAGRAM....................12 FIGURE 2: SIM5360-PCIE PIN OUT DIAGRAM ......................13 FIGURE 3: DIMENSIONS OF SIM5360-PCIE(UNIT: MM)） ..................15 FIGURE 4: SIM CARD HOLDER REFERENCE CIRCUIT..................18 FIGURE 5: RESET TIMING ............................19 FIGURE 6: LED_WWAN# REFERENCE CIRCUIT......................

  • Page 6: Version History

    Smart Machine Smart Decision Version History Date Version Description of change Author 2014-04-01 1.01 Origin Libing Modify pin names of SIM5360-PCIE 2014-07-10 1.02 Libing Modify figure1 and figure4. Modify weight of SIM5360-PCIE 2015-01-22 1.03 Libing Modify table 18. SIM5360-PCIE_Hardware_Design 2015-01-22...

  • Page 7: Introduction

    Smart Machine Smart Decision 1. Introduction SIM5360-PCIE module is PCI Express Mini Card. This document describes SIM5360-PCIE hardware interface in great detail, which can help user to quickly understand SIM5360-PCIE interface specifications, electrical and mechanical details. SIM5360-PCIE_Hardware_Design 2015-01-22...

  • Page 8: Sim5360-Pcie Overview

    Smart Machine Smart Decision 2. SIM5360-PCIE Overview SIM5360-PCIE series support quad-band GSM/GPRS/EDGE and dual-band UMTS/HSDPA/HSUPA/HSPA+, which work on frequencies GSM850,EGSM900,DCS1800,PCS1900,WCDMA2100/900 or WCDMA1900/ WCDMA850 or WCDMA2100/ WCDMA850 The modules can be chosen based on the wireless network configuration. In this document, the entire radio band configuration of SIM5360-PCIE series is described in the following table.

  • Page 9: Sim5360-Pcie Key Features

    Smart Machine Smart Decision 2.1. SIM5360-PCIE Key Features Table 2: SIM5360-PCIE Key Features Feature Implementation Power supply Single supply voltage 3.3V+0.3V/-0.1V Dual-mode UMTS/HSPA+/EDGE/GPRS operation ● GPRS Class B, multislot class 12 operation, Supports coding scheme: ● CS1-4 EDGE multislot class 12 operation, Supports coding schemes ●...
  • Page 10 Smart Machine Smart Decision GPRS coding scheme Max data rata（4 slots） Modulation type CS 1 = 9.05 kb/s / time slot 36.2 kb/s GMSK CS 2 = 13.4 kb/s / time slot 53.6 kb/s GMSK CS 3 = 15.6 kb/s / time slot 62.4 kb/s GMSK CS 4 = 21.4 kb/s / time slot...

  • Page 11: Operating Mode

    Smart Machine Smart Decision 2.2. Operating Mode The table below summarizes the various operating modes of SIM5360-PCIE. Table 4: Operating Mode Mode Function Normal GSM/GPRS/EDG Module will automatically go into sleep mode if the conditions of sleep operation E/WCDMA/HSP mode are enabling and there is no on air and no hardware interrupt (such as A+ SLEEP GPIO interrupt or data on serial port).
  • Page 12 Smart Machine Smart Decision Figure 1: SIM5360-PCIE Functional Diagram SIM5360-PCIE_Hardware_Design 2015-01-22...

  • Page 13: Package Information

    Smart Machine Smart Decision 3. Package Information 3.1. Pin Out Diagram Figure 2: SIM5360-PCIE Pin Out Diagram SIM5360-PCIE_Hardware_Design 2015-01-22...

  • Page 14: Pci Express Mini Card Connector Pin Description

    Smart Machine Smart Decision 3.2. PCI Express Mini Card Connector P in Description Table 5: PCI Express Mini Card Connector Pin Description Pin name Pin number Description Comment Power supply 2,39,41,52 3.3 Power supply for module 4,9,15,18,21, 26,27,29,34,3 Ground 5,37,40,43,50 Reset PERST# Reset input (Active low)

  • Page 15: Package Dimensions

    Smart Machine Smart Decision 3.3. P ackage Dimensions Figure 3: Dimensions of SIM5360-PCIE(Unit: mm)） Please refer to appendix for package dimension details. SIM5360-PCIE_Hardware_Design 2015-01-22...

  • Page 16: Application Interface

    Smart Machine Smart Decision pplication Interface 4.1. P ower Supply The recommended power supply voltage of SIM5360-PCIE is 3.3V. Table 6: Recommended 3.3V Power Supply Characteristics Symbol Parameter Type Unit Power supply voltage Supply current capability 2000 4.2. ower Saving Mode SIM5360-PCIE has two power saving modes: minimum functionality mode and sleep mode.

  • Page 17: Wake Up Sim5360-Pcie From Sleep Mode

    When module is powered on, and connected USB_DP, USB_DN and GND to PC, and driver installed successfully, then 5 COM port, “SIMTECH HS-USB Modem 9000”, “SIMTECH HS-USB NMEA 9000”, “SIMTECH HS-USB AT port 9000”, “SIMTECH HS-USB Diagnostics 9000” and “SIMTECH Wireless HS-USB Ethernet Adapter 9000”...

  • Page 18: Pcm Interface

    Smart Machine Smart Decision Figure 4: SIM Card Holder Reference Circuit SIM card circuit is susceptible to be interfered, causing the SIM card failure or some other issues, so it is strongly recommended to follow these guidelines while designing:  Make sure that SIM card holder should stay away from GSM antenna while in PCB layout;...

  • Page 19: Perst

    Smart Machine Smart Decision Data Ordering Note: PCM interface can be control by AT command. For more details please refer to document [1] and document [2] Table 10: PCM DC Characteristics Symbol Parameter Type Unit High-level input voltage 1.26 Low-level input voltage -0.3 0.63 High-level output voltage...

  • Page 20: W_Disable

    Smart Machine Smart Decision 4.7. W_DISABLE# The W_DISABLE# pin controls SIM5360-PCIE to enter or exit the Flight mode by default. In Flight mode, RF function is closed to prevent interference with other equipments or minimize current consumption. Table 12: Flight mode control Function W_DISABLE# status Module operation Low Level...

  • Page 21: Wake

    Smart Machine Smart Decision 4.9. WAKE# The WAKE# pin can be used as an interrupt signal to host. Normally it will keep high logic level until certain condition such as receiving SMS, voice call (CSD, video) or URC reporting, then WAKE# will change to low logic level to inform the master (client PC).

  • Page 22: Smt Antenna Connector

    Smart Machine Smart Decision 4.10. SMT Antenna Connector SIM5360-PCIE have two antenna connectors, one is the main GSM/WCDMA antenna connector, the other is WCDMA diversity antenna connector. Recommended antenna characteristics of SIM5360-PCIE are described by following tables. Table 15: Recommended Passive Antenna Characteristics Passive Recommended standard Direction...

  • Page 23: Electrical, Reliability And Radio Characteristics

    Smart Machine Smart Decision 5. Electrical, Reliability and Radio Characteristics 5.1. Absolute Maximum Ratings The absolute maximum ratings are described by the following table. Module may be damaged beyond these ratings. Table 17: Absolute maximum ratings Symbol Parameter Type Unit VCC input voltage VCC total peak current Input current...

  • Page 24: Usim_Vdd Characteristics

    Smart Machine Smart Decision USIM_VDD=1.8V 0.36 USIM_VDD=3.0V 0.36 USIM_VDD=1.8V 1.62 USIM_VDD=3.0V USIM_CLK USIM_VDD=1.8V 0.216 USIM_VDD=3.0V USIM_VDD=1.8V USIM_VDD=3.0V USIM_VDD=1.8V 0.27 USIM_VDD=3.0V USIM_DATA USIM_VDD=1.8V USIM_VDD=3.0V USIM_VDD=1.8V 0.27 USIM_VDD=3.0V 5.4. USIM_VDD Characteristics Table 20: USIM_VDD Characteristics Symbol Parameter Type Unit 2.85 3.15 Output voltage 1.80 Output current 5.5.

  • Page 25: Electro-Static Discharge

    Smart Machine Smart Decision DATA mode, GPRS ( 3Rx, 2 Tx ) CLASS 12 GSM 850 @power level #5 <460mA,Typical 360mA GSM 900 @power level #5 <440mA,Typical 325mA DCS1800 @power level #0 <400mA,Typical 285mA PCS1900 @power level #0 <300mA,Typical 295mA EDGE Data DATA mode, EDGE( 1 Rx,4 Tx ) CLASS 12 GSM 850...

  • Page 26: Radio Characteristics

    Smart Machine Smart Decision Table 22: ESD characteristics (Temperature: 25℃, Humidity: 45 %) Contact discharge Air discharge ±5KV ±10KV ±5KV ±10KV Antenna port ±5KV ±10KV USB_DP,USB_DN ±4KV ±8KV 5.7. Radio Characteristics 5.7.1. Conducted Output Power The following table shows SIM5360-PCIE’s conducted output power, comply with 3GPP TS 05.05and TS 34.121.

  • Page 27: Supported Band

    Smart Machine Smart Decision 5.7.3. Supported Band The following table shows SIM5360-PCIE supported band, and complies with 3GPP spec. Table 25: Supported Band Frequency Receiving Transmission GSM850 869 ～894 824 ～849 E-GSM900 925 ～960 880 ～915 DCS1800 1805～1880 MHz 1710～1785 MHz PCS1900 1930～1990 MHz 1850～1910 MHz...

  • Page 28: Appendix

    Smart Machine Smart Decision 6. Appendix I. SIM5360-PCIE Top and Bottom View Figure 10: SIM5360-PCIE Top and Bottom View SIM5360-PCIE_Hardware_Design 2015-01-22...

  • Page 29: Dimensions Of Sim5360-Pcie

    Smart Machine Smart Decision Dimensions of SIM5360-PCIE Figure 11: Dimensions of SIM5360-PCIE (Unit: mm Top view) SIM5360-PCIE_Hardware_Design 2015-01-22...
  • Page 30 Smart Machine Smart Decision Figure 12: Dimensions of SIM5360-PCIE (Unit: mm Bottom and Side view) SIM5360-PCIE_Hardware_Design 2015-01-22...

  • Page 31: Related Documents

    Smart Machine Smart Decision III. Related Documents Table 26: Related Documents Document name Remark SIMCOM_SIM5360_ATC_EN_ V1.XX.doc SIM5360_Audio_Application_ SIM5360_Audio_Application_Note Note ITU-T Draft Serial asynchronous automatic dialing and control recommendation V.25ter: Digital cellular telecommunications (Phase 2+); AT command set for GSM 07.07: GSM Mobile Equipment (ME) GSM 07.10: Support GSM 07.10 multiplexing protocol...

  • Page 32: Terms And Abbreviations

    Smart Machine Smart Decision IV. Terms and Abbreviations Terms and Abbreviations Table 27: Abbreviation Description Analog-to-Digital Converter Adaptive Multi-Rate Coding Scheme Circuit Switched Data Clear to Send Data Terminal Equipment (typically computer, terminal, printer) Data Terminal Ready Discontinuous Transmission Enhanced Full Rate EGSM Enhanced GSM Electrostatic Discharge...
  • Page 33 Smart Machine Smart Decision Terminal Equipment, also referred to as DTE Transmit Direction UART Universal Asynchronous Receiver & Transmitter Unsolicited Result Code USSD Unstructured Supplementary Service Data Phonebook abbreviations SIM fix dialing phonebook SIM last dialing phonebook (list of numbers most recently dialed) Mobile Equipment list of unanswered MT calls (missed calls) SIM (or ME) own numbers (MSISDNs) list Mobile Equipment list of received calls...

  • Page 34: Safety Caution

    Smart Machine Smart Decision V. Safety Caution Table 28: Safety caution Marks Requirements When in a hospital or other health care facility, observe the restrictions about the use of mobiles. Switch the cellular terminal or mobile off, medical equipment may be sensitive to not operate normally for RF energy interference.
  • Page 35 Smart Machine Smart Decision Contact us: Shanghai SIMCom Wireless Solutions Ltd. Add: SIM Technology Building, No.633,Jinzhong Road, Changning District, Shanghai P.R. China 200335 Tel: +86 21 3235 3300 Fax: +86 21 3235 3301 www.sim.com/wm URL: SIM5360-PCIE_Hardware_Design 2015-01-22...
