Backlight
The backlight options are:
1) Auto off, the display backlight will go out if the buttons are not used for a period of time.
2) Allways on, the display backlight will remain on.
Use the up and down button to change your setting.
Press menu to store the setting and go back to the setup menu.
Clear to default
To put the device in its default setting press and hold the Up and down key at the same time.
Default settings are:
-
DMX port
output
-
DMX universe
-
IP address 2.x.x.x (x.x.x factory unique address)
-
Netmask 255.0.0.0
-
Name dmXLAN node1 xxx (xxx is serial number)
Technical Specifications:
Ethernet:
Hardwired KRONE contact or
NEUTRIK Ethercon
DMX port:
DMX512 on 3/5 pin (fe)male XLR
Display:
2 lines 8 characters
Power:
9-48 Vdc or POE (IEEE 802.3af)
Dimensions
110 x 70 x 50 mm
General Information
CE – Product
The DmxLan Node1 permits to the CE requirements set up by the European Community. This can be
recognized by this label on the outside of the product:
0-0
Designed and manufactured in the Netherlands by:
ELC lighting
Support contact: support@elclighting.com
Worldwide distribution:
ANIMA lighting Ltd
Rte du Stand 20
CH-1897 Le Bouveret
Switzerland
Tel: +4179 210 46 13
Fax: +41860 79 210 46 13
Email: sales@elclighting.com
URL: www.elclighting.com
4
