Williams Sound Language Interpretation System WIR SYS 4 Specification Sheet page 5

SoundPlus ® Language Interpretation System •
D
D
Maximum Range When Using the RX22-4 Infrared Receiver
Fig. 7: Horizontal and Vertical Radiation Polar Plots
HORIZONTAL RADIATION POLAR PATTERNS
DISTANCE FROM EMITTER TO 1 nW/sq cm CONTOUR
– 90
– 80
200
60
180
54
48 160
140
42
120
36
100
30
80
24
60
18
40
12
20
6
80
90
1 Channel, 1 nW/sq cm
(Approx. 28000 sq ft, 2600 sq m)
2 Channel, 1 nW/sq cm per channel
(Approx. 18000 sq ft, 1700 sq m)
4 Channel, 1 nW/sq cm per channel
(Approx. 11000 sq ft, 1000 sq m)
Reflections of the infrared light from walls, ceilings, and floors may change these patterns.
Important: Remember to point the emitter towards the listening audience!
If you're not getting sufficient coverage with a single, properly installed TX9 Emitter, you may need
to add additional WIR TX9 Emitters to achieve full coverage of your listening area. Figures 8a and
8b illustrate how multiple emitters can be used for large room installations.
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
©2006, Williams Sound Corp. MCAT 030D
– 70
– 60
– 50
– 40
– 30
– 20
– 10
0
10
20
30
40
50
60
70
VERTICAL RADIATION POLAR PATTERNS
DISTANCE FROM EMITTER TO 1 nW/sq cm CONTOUR
– 90
– 80
200
60
180
54
48 160
140
42
120
36
100
30
80
24
60
18
40
12
20
6
80
90
1 Channel, 1 nW/sq cm
2 Channels, 1 nW/sq cm per channel
4 Channels, 1 nW/sq cm per channel
5
Model WIR SYS 4
