PDW30 & PDW90 Repeater Field Unit
Instruction Manual
Wireless Repeater Unit in a Rugged, Industrial Housing
•
•
Simple to Order, Configure, & Install
Increase Range an Additional 1 Mile Line-of-Sight, 500 Ft Indoor
•
Remote or Attached Antenna
•
•
Flanges for Wall or Pipe Mounting
•
Software Available for Even Easier Setup
Rugged, IP68, NEMA 4X Enclosure
•
•
3-Year Warranty
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA
Tel (800) 343-1001 • Fax (508) 655-8990
www.predig.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Precision Digital Corporation PDW30-RNA
Summary of Contents for Precision Digital Corporation PDW30-RNA
- Page 1 Flanges for Wall or Pipe Mounting • Software Available for Even Easier Setup Rugged, IP68, NEMA 4X Enclosure • • 3-Year Warranty PRECISION DIGITAL CORPORATION 233 South Street • Hopkinton MA 01748 USA Tel (800) 343-1001 • Fax (508) 655-8990 www.predig.com...
-
Page 2: Introduction
Instruction Manual Introduction Disclaimer The information contained in this document is Precision Digital PDW30-RNA wireless signal repeat- subject to change without notice. Precision Digital ers are used to retransmit wireless signals when con- Corporation makes no representations or nectivity between PDW30 or PDW90 wireless units is warranties with respect to the contents hereof;... -
Page 3: Table Of Contents
Figure 1. PDA6963-SS Stainless Steel Pipe Mounting Kit ........ 6 Figure 2. Enclosure Dimensions – Front View ........... 6 Figure 3. Enclosure Dimensions – Side Cross Section View ......6 Figure 4. PDW30-RNA Device Assembly, Rear View ......... 7 Figure 5. Power Connections ................7... -
Page 4: Specifications
PDW30 & PDW90 Repeater Field Unit Instruction Manual Specifications Wireless Radio Frequency Except where noted all specifications apply to operation at +25°C. 900 MHz General Range 500 ft (152.4 m) indoor, 1 mi (1.61 km) outdoor (line-of-sight) Display 32-character dual-line alphanumeric dot Encryption AES 128-bit encryption available using matrix LCD display with backlight... -
Page 5: Safety Information
Mounting Instructions The PDW30-RNA has two mounting holes that may be used for a 1.5" pipe mounting or wall mounting. Alternatively, the unit may be supported by the con- duit using the conduit holes provided. The antenna is threaded into one of the three conduit holes and may be moved as appropriate for the installation. -
Page 6: Canada (Ic) Notice
PDW30 & PDW90 Repeater Field Unit Instruction Manual Mounting Dimensions The RF module has been certified for remote and • All units: inches [mm] base radio applications. If the module will be used for portable applications, the device must undergo SAR testing. -
Page 7: Connections
Power connections are made to a two-terminal con- steel screws. Remove the electronics assembly from nector labeled POWER in Figure 4. The PDW30-RNA the enclosure. The power connection is made to a two is reverse polarity protected; it will not be damaged if terminal removable connector on the back of the as- wired backward. -
Page 8: Setup And Programming
Select a menu item of option Previous Cycle backward through menus or increment digit Next Cycle forward through menus or select next digit Display for PDW30-RNA Repeater Unit Display Status Received Signal Strength Indicator Indicates the wireless signal strength between wireless devices on a scale of 1 to 10. -
Page 9: Pdw Manager Software
Instructions on the use of PDW Manager to program Press the Enter button, at any time, to accept the the PDW30-RNA wireless units can be found under value or the Menu button to exit without saving. Programming with PDW Manager on page 11. -
Page 10: Password Setup
PDW30 & PDW90 Repeater Field Unit Instruction Manual Password Setup The wireless repeater may be protected with a four digit numeric password in order to prevent unauthor- ized tampering. When a password has been set, you will be prompted to enter that password in order to ac- cess the device menu. -
Page 11: Programming With Pdw Manager
Programming with PDW Manager PDW Manager allows you to program the PDW30-RNA wireless repeater unit from a PC with a USB connection. The unit connects to a PC via the micro USB connection on its face, underneath the enclosure cover. Use of PDW Man- ager is required for programming advanced settings such as wireless encryption. - Page 12 PDW30 & PDW90 Repeater Field Unit Instruction Manual Device communication can be secured by enabling 128-bit AES encryption. A channel mask may also be set for interference immunity. The encryption key and channel mask may be entered on the Advanced tab. Once you have entered the encryption information, click Save Settings.
- Page 13 Email: sales@predig.com Place Orders Email: orders@predig.com For the latest version of this manual please visit www.predig.com PRECISION DIGITAL CORPORATION 233 South Street • Hopkinton MA 01748 USA Tel (800) 343-1001 • Fax (508) 655-8990 www.predig.com LIMW30R_C SFT102 Ver 1.000 & up...
