- Page 1 Wi-Fi Controlled Pressure Filter Pond filter and UVC Instruction Manual IMPORTANT: Please read this instruction manual carefully before using this product. Keep the manual safe for future reference.
- Page 2 UV, and the power sockets must be connected to an earth. 4. The Bermuda Pressure Filter is intended for outdoor use only. Although shower proof it must never be placed in the pond. 5. The filter must never be used to filter any flammable liquids, or water over 35⁰C.
- Page 3 • Can be buried in the ground up to its lid. • Water can be pumped through the filter then uphill • Capable of high flow-through of water • Ideal for use with Bermuda Filter Force pumps Usage Only suitable for outside garden ponds. UV can be run continuously, 24 hours per day.
-
Page 4: Filter Setup
Filter set-up Filter maintenance Step 1 - To clean the filter turn the valve Step 2 - Wind handle on filter to squeeze from RUN to CLEAN. Water will stop sponge inside and help remove dirt. returning to pond and instead leave by Dirty water will then be pumped out of the drain on the rear of the filter lid. - Page 5 Filter maintenance (continued) Step 5 - Lift the lid and connected Step 6 - Remove the bottom shield sponges out of the filter body and turn upside down Step 7 - Using a screwdriver (not supplied) Step 8 - Sponges can then be lifted off undo the screws in the bottom and replaced.
- Page 6 UVC maintenance Step 1 - Prize off the valve with a Step 2 - Unscrew the 3 screws. screwdriver. ENSURE POWER IS SWITCHED OFF. Step 3 - Lift off the blue filter casing. Step 4 - Undo the screws on the lid of the UV compartment.
-
Page 7: Troubleshooting
5. If filter sponges do not spring back after cleaning, replace old sponges for new. Specifications MODEL BER CODE OUTPUT POWER MAX HEIGHT 10000 BER0101 10,000 litres / 2,200 gallons 3,500lph / 770gph 15000 BER0102 15,000 litres / 3,300 gallons 5,000lph / 1,100gph... - Page 8 Exploded view - Pressure filter...
- Page 9 Exploded view - UVC...
- Page 10 Exploded view - Sponge...
- Page 11 Bermuda retailer. Should your Bermuda product stop working refer first to trouble shooting and if this does not help, return the product to the place of purchase.
- Page 12 BERMUDA an Evolution Aqua brand. Evolution House, Kellet Close, Wigan, Lancashire, WN5 0LP DISTRIBUTED BY: Certikin, Witan Park, Avenue 2, Station Lane Industrial Estate, Witney, Oxfordshire, UK, OX28 4FJ...
