- Page 1 Wi-Fi Controlled Pressure Filter Pond filter and UVC Instruction Manual IMPORTANT: Please read this instruction manual carefully before using this product. Keep the manual safe for future reference. Manual version - 29.05.2018...
-
Page 2: Table Of Contents
UV clarifier, to create clear, healthy pond water. Being pressurised, the Bermuda Wi-Fi Controlled Pressure filter is easy to hide in ground with only the top 20 cm visible. Even a long distance away from the pond, hidden away from view - like at the top of a stream. - Page 3 • Can be buried in the ground up to its lid. • Wide inner diameter capable of high flow-through of water. • Ideal for use with Bermuda Filter Force pumps. Usage Only suitable for outside in garden ponds - not swimming ponds.
-
Page 4: Safety Instructions
Safety instructions 1. Electrical installation must be in accordance with local regulation. They should not be placed near the pond - but at least 2 metres away. Make sure that plugs and sockets are always dry. 2. Equipment can only be worked with the socket which has safety earthing protection. -
Page 5: Specifications
Max combined load socket A+B = 800 watt Max working pressure for filter is 0,3 bar = 3 m. What is included: 1 x Bermuda Wi-Fi Controlled Pressure Filter 3 x Hose connectors (for 32/40/50 mm hose) 3 x Locking nuts... -
Page 6: Description
The function of the filter gives you one of the most efficient filter systems available, and it has several different filter systems built in. The Bermuda Wi-Fi Controlled Pressure Filter does not need a prefilter. 1. Filter sponges with different pore sizes for both oxygen-consuming and non-oxygen-consuming bacteria. -
Page 7: How The Filtration Works
How the filtration works A: Inlet Dirty water from the pond pump (not included) passes via a hose through the inlet into filter. B: Vortex system Under the action of gravity, suspended solids and mud are separated. C: Mechanical filter When the water passes through the filter sponges into the internal chamber, dirt particles will be caught on the first... -
Page 8: Installation
Installation 1. Filter should be installed with a min. distance to the pond of 2 m. on a stable base or in ground with the top 20 cm. above - to allow access to open the lid clamp. Make sure that the filter and sockets cannot be flooded in case of heavy rain or low placement. -
Page 9: Control Panel / Manual Operation
Control panel and manual operation 5. Touch Button "Wi-Fi / UV - Double Function. This button is used to set Wi-Fi connection / Enable use with mobile app at long press. See fig. 6. At short press, it turns on and off for the filter's UV-C light. The light can be seen through the small transparent glass on top of the UV-C unit. -
Page 10: First Time App Installation
First time installation of App me@bermudawatergardens.com 1. Search and download the 2. First time you open the App 3. Fill in your e-mail and App “Pondlink” from App store you will have to register as password (optional other / Google play and install. a minimum your email and a details) and press “Get code”. - Page 11 Enter your serialno. 7. Locate the serial no. on the 8. Fill in your serial no. and 9. Select network (2.4G). label over the cable on your press ”Link”. filter and Press ”+” to connect to filter. My-Wi-Fi-network 11. If your network signal is ok 10.
-
Page 12: Setting Timers And Options
Setting timers and options 13. You see temperature and 14. Here it is counting down 15. Timer can be set from manage settings here. to next cleaning and options once a week to once a day. First option is setting for the to set timer, watersaving, A good option if you need to automatic cleaning function. - Page 13 19. You can also activate an 20. Press ”>”to start the clean- 21. The time adjustment gives extra manual cleaning process ing process. Further you can you the option to adjust to the at any time to check function set the time for the process best cleaning process depending or for extra maintenance.
- Page 14 Sockets A for pump and B for other pond-equipment 27. Other options can be enabled, 25. Socket A is reserved for 26. Keep In Pump mode but we do not recommend that this the pump supplying the filter ! where other functions are socket is used for anything else Assuring safety and functions.
-
Page 15: Other Functions
Other functions / change serialno. / install options 32. Check and install firmware updates for Wi-Fi connection. Delete present Pondlink device from App. A reinstallation will reset all functions if system should ever lock up. Change filter password for security and privacy: A. - Page 16 Check/Cleaning/Replacing the filter sponges After 1-2 seasons or when the water flow is reduced - and it does not help to clean using the automatic cleaning function. The sponges should be checked/manually washed or replaced. Do not use any kind of detergent as this will kill the microorganisms in the sponges. Over winter the filter should also be cleaned and have a service check before storing indoor for winter - please see seasonal care Turn off the filter and disconnect the power cord from the switch.
- Page 17 Filter maintenance (continued) Step 5 - Please take care not to loose the Step 6 - Now the filter sponges can be plastic bearing on the foam side of the removed. The plastic holders in the middle plate when removing the base plate. of the sponges are easy to remove.
-
Page 18: Replacement Of Uv Lamp
Replacement of UV lamp ENSURE POWER IS SWITCHED OFF AND POWER CORD OF FILTER UNPLUGGED Step 1 - Unscrew the four screws under Step 2 - Pull up the UV-unit by pressing the rubber plugs on the lid of the UV- with your thumbs on the lid and lifting unit. - Page 19 Seasonal care - required precautions Take care of - and prevent the following conditions: Frost. The filter must be dismantled when frost is foreseen at the latest at +4ºC. Clean the filter and take the opportunity to grease and replace O-rings and UV-bulb - this will keep your filter in good condition for many years.
-
Page 20: Troubleshooting
Trouble shooting 1. If water is leaking around the hosetails, check that the supplied rubber washers have been fitted. Check that the hose is the right size for the hosetail and that the hoseclip has been properly tightened. 2. If water is leaking from the clamp, check that it is done up properly and tight, and that the O-ring is present inside the filter casing. -
Page 21: Faq
Can others connect to my filter ? Once installed and locked to your local Wi-Fi network and your mobile – you (and only you – unless you have allowed others to make an equal local installation) can access your filter from any network connection. You can allow remote connection by providing your serial no. -
Page 22: Exploded View
Exploded view... - Page 23 20000 30000 Common Screws UV-ballast Square Rubber gasket Double O-ring ballast UV-C Lamp Double O-ring quartz Quartz glass set Quartz glass locking nut Filter lid Seal gasket Hose connector Locking nut Sponge set fine (Y) and coarse (B) Base plate UV-bottom shield Biological media casette Lid clamp...
-
Page 24: Guarantee
Bermuda retailer. Should your Bermuda product stop working refer first to trouble shooting and if this does not help, please contact your Bermuda retailer. If still unsolved - please return the product to the place of purchase in a clean condition. -
Page 25: Privacy And Data Protection
Your privacy and dataprotection We highly value your privacy – so any information submitted to us will only be used for our own reference and not shared in any way unless agreed by you. App related: In order to provide our service relating to the Pondlink program, we need to keep certain information in a database. -
Page 26: Storage Page
Storage page Please place the label from the packing and your proof of purchase on this page along with any receipts when having your filter maintained by a qualified professional. -
Page 27: Notes
Notes... - Page 28 Pondlink® filters have international registered design and patents – further patents pending. Copyright Evolution Aqua www.bermudawatergardens.com BERMUDA an Evolution Aqua brand. Evolution House, Kellet Close, Wigan, Lancashire, WN5 0LP DISTRIBUTED BY: Certikin, Witan Park, Avenue 2, Station Lane Industrial Estate, Witney, Oxfordshire, UK, OX28 4FJ...
