SERVICE MANUAL
-Steam Steriliser-
FOREWORD
This manual IS NOT an integral part of the steriliser.
The manual is addressed to qualified, specialised technicians for routine maintenance
and repairs.
Technicians or operators mused be authorised in writing by COMINOX.
Technicians must read this manual and follow the instructions herein contained. COMINOX
is not liable for any injury and/or damage to people or property or to the steriliser itself
should the conditions herein illustrated be disregarded.
This manual contains industrial secrets which must not be disclosed. The manual and its
annexes must not be edited, modified, copied or given to third parties unless authorised
by COMINOX.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STERILCLAVE 18 and is the answer not in the manual?

Questions and answers

Summary of Contents for COMINOX STERILCLAVE 18

  • Page 1 Technicians or operators mused be authorised in writing by COMINOX. Technicians must read this manual and follow the instructions herein contained. COMINOX is not liable for any injury and/or damage to people or property or to the steriliser itself should the conditions herein illustrated be disregarded.
  • Page 3: Table Of Contents

    Contents CONTENTS CONTENTS ............................3 Reference list ............................ 5 Graphical reference representation Model 6 S Dynamica ............. 6 Graphical reference representation Model 18................7 Graphical reference representation Model 24................8 Graphical reference representation of common components ..........9 TECHNICIAN MENU ........................11 Inputs ...............................
  • Page 4 Contents Door alarm............................38 PT1 temperature probe alarm..................... 39 Drain alarm ............................. 39 Misalignment alarm........................39 Pressure transducer alarm......................40 Manual stop alarm ........................40 Power missing alarm........................40 Event alarm............................. 40 Alarm code list ..........................41 ADDITIONAL CHECKS AND SETTINGS................... 42 Display off or not clear........................
  • Page 5: Reference List

    Contents Reference list 03, Power cable 05, Measuring funnel 06, SterilCard 08, Tray support 09, Chamber 10, Clean water tank 11, Waste water recovery tank 12, Safety valve 13, Main switch 14, Filler 15, Air sterilisation filter 16, Door 17, Safety thermostat 18, Door 19, Coil grid 20, Drain filter...
  • Page 6: Graphical Reference Representation Model 6 S Dynamica

    Contents Graphical reference representation Model 6 S Dynamica...
  • Page 7: Graphical Reference Representation Model 18

    Contents Graphical reference representation Model 18...
  • Page 8: Graphical Reference Representation Model 24

    Contents Graphical reference representation Model 24...
  • Page 9: Graphical Reference Representation Of Common Components

    Contents Graphical reference representation of common components...
  • Page 11: Technician Menu

    Technician Menu TECHNICIAN MENU Insert the Technician’s SterilCard to access the Technician Menu. If the steriliser is not equipped with a SterilCard reader, a Technician’s SterilCard kit may be employed. The kit includes a reader, a Technician’s SterilCard and a cable for connecting the reader to logic board 33 (connector J5).
  • Page 12 Technician Menu Use the ↑↓ arrows to scroll the list and highlight the required option. Press ENTER to access the selected option. Press to go back to the MENU page.
  • Page 13: Inputs

    Technician Menu Technician Menu Inputs The status of the steriliser inputs can be displayed: • S1 is the clean water tank 10 safety probe • S2 is the clean water tank 10 minimum level probe • S3 is the clean water tank 10 maximum level probe •...
  • Page 14: Outputs

    Technician Menu Outputs The status of the steriliser outputs can be displayed and modified: • EV1 charge to which the water inlet pump 35 is connected in parallel (included on all models) • EV2 drain (included on all models) • EV3 3-way (not included on 6/18 S Dynamica models) •...
  • Page 15: Pt1 / Pt2 / Pt3 Board Calibration

    Technician Menu PT1 / PT2 / PT3 board calibration This procedure is used to calibrate temperature probe PT1, PT2 and PT3. A specific calibration kit is needed for calibration: 0-5V switch To calibrate PT1, PT2 or PT3 press option 3, 4 or 5 respectively in the Technician Menu:...
  • Page 16 Technician Menu Disconnect the connector corresponding to the temperature probe you want to calibrate from the electronic power board 34: disconnect connector CN12 for sensor PT1, connector CN13 for sensor PT2 or connector CN14 for sensor PT3. Using the cable included in the kit, connect connector CN1 of the calibration tool (which corresponds to a 1000 Ohm sample coil, corresponding to 0°C) to connector CN12, CN13 or CN14 of the power board 34: Wait for at least 10 seconds and press ENTER.
  • Page 17 Technician Menu Disconnect the cable from connector CN1 of the calibration tool and connect connector CN2 of the calibration tool (1573 Ohm sample coil, corresponding to 150°C) to calibrate the sensor PT1 or the connector CN3 (1832 Ohm sample coil, corresponding to 220°C) to calibrate sensors PT2 and PT3.
  • Page 18: Tp Board Calibration

    Technician Menu TP board calibration This procedure is used to calibrate the pressure transducer: Disconnect the connector CN11 corresponding to the pressure transducer from the electronic power board 34:...
  • Page 19 Technician Menu Using the cable included in the kit, connect connector CN4 of the calibration tool to connector CN11 of the power board 34. Set the calibration tool switch to 0 Vdc. Wait for at least 10 seconds and press ENTER. Now set the calibration tool switch to 5 Vdc.
  • Page 20: Pt1 / Pt2 / Pt3 Probe Calibration

    Technician Menu PT1 / PT2 / PT3 probe calibration This procedure is used to complete the calibration of the temperature probes PT1, PT2 and PT3. This operation must be performed whenever a temperature probe is replaced. Press +/- to enter a 0°C value of the temperature probe shown on the label or on the wire sheath (e.g.: if a value of 1000.2 is shown on the PT1 sensor label, press + twice to display 1000.2).
  • Page 21: Continuous Cycle

    Technician Menu Continuous cycle A CONTINUOUS CYCLE is a test cycle which includes pre-vacuum, 2 fractioned vacuum pulses, pressurisation, sterilisation (2 minutes) and drying (3 minutes). Minimum pressure values higher than standard cycles are reached during the vacuum phases. The purpose of the test cycle is to run the steriliser continuously, for instance at night, to test efficacy of the performed maintenance operations: Press +/- to enter the number of cycles and press ENTER to confirm.
  • Page 22: Chamber Load Test

    Technician Menu Chamber load test This test can only be run on 18 S Dynamica and 18/24 S - B - BHD models. Do not run this test on 6 S Dynamica. Press ENTER to operate the water inlet pump 35. The following screen will be displayed: Press STOP to stop loading the chamber.
  • Page 23: Accessories

    Technician Menu Accessories Select Accessories (option 16) and press ENTER. The external charge value (ON/OFF) will appear. Press ↑↓ to change the value, press ENTER to confirm and move to the next option. Press to go back to the Technician Menu without changing accessory settings. Delete maintenance Press YES to delete all maintenance interventions performed on the steriliser from the machine memory and reset the remaining day and cycle counters for all components.
  • Page 24: Simplified Version Of The Technician Menu (Puck)

    Technician Menu Simplified version of the Technician Menu (PUCK) To access the simplified version of the Technician Menu when the Technician’s SterilCard is not available, simultaneously press the second and fourth button on the left and switch the steriliser on using main switch 13. The following screen will appear: This Technician Menu contains only two options: 1.
  • Page 25: Maintenance

    Maintenance MAINTENANCE In STAND BY, press MENU and use ↓ to select the Maintenance Menu (option 5). Press ENTER to display the following screen: This menu contains only two options: 1. Items 2. Save maintenance Items Press ENTER to display the list of items subject to scheduled maintenance: The remaining days and cycles and the last three replacements are shown for each item with the date of intervention and the total number of cycles when the replacement was performed.
  • Page 26: Save Maintenance

    Maintenance Press ENTER to record replacement: Press YES to store replacement information in the maintenance memory. Press NO to go back to the list of items. Save maintenance Press ENTER to display the following screen: Press NO to go back to the Maintenance Menu. Press YES to store the maintenance operation on the inserted SterilCard 06.
  • Page 27: Scheduled Service Table

    Maintenance Scheduled service table Number of Number of cycles or cycles Item Service date performed at Technician signature allowed intervention time operation Air filter* 1 year 1500 Water filter 2 years 1000 Vacuum pump kit 2 years 1500 EV2 drain 2 years 3000 EV6 by-pass...
  • Page 28: Messages

    Messages MESSAGES Messages contain information and warnings and usually require the user to perform a simple correction or check. Message / Cause / • Solution Scheduled maintenance This message indicates the need for a scheduled maintenance on one or more components.
  • Page 29 Messages Waste water recovery tank 11 Waste water recovery tank 11 on models 24 on models 18 - the probes and steriliser grounding, as correct steriliser operations depend on the correct grounding connection. If the steriliser is not used for a long period, empty out the tanks and clean them carefully with a cleaning solution (70% water and 30% alcohol).
  • Page 30: Cooling Pause

    Messages Cooling pause This message indicates that the temperature in chamber 09 is too high to start or continue a cycle (see USE AND MAINTENANCE MANUAL, chapter OPERATION). The steriliser will display this message in STAND BY mode or after starting a cycle and will stop only during the pre-vacuum phase.
  • Page 31: Alarms

    Alarms ALARMS Alarms indicate the presence of a possible fault and the need for repairs. If a fault occurs during a cycle, the cycle will be immediately interrupted and a buzzer will sound for 15 seconds to indicate the alarm conditions. A description of the alarm will appear on the display along with the cycle and phase when the alarm occurred.
  • Page 32: Chamber Level Alarm

    Alarms buzzer will sound for 3 seconds when the “Maximum water level” is reached to indicate that the tank is full. If you do not hear the signal, excess water will flow out from the filler. • If the alarm is displayed during the cycle, fill the tank and proceed as shown in the INSUFFICIENT STEAM ALARM procedure.
  • Page 33: Insufficient Steam Alarm

    Alarms Insufficient steam alarm This alarm indicates leakage of steam from chamber 09. The alarm may appear during a cycle, when the suitable pressure needed to run a cycle is not reached at a temperature of 114°C. Pressure is detected by transducer 38 and temperature by chamber temperature probe 39.
  • Page 34: Pressurisation Alarm

    Alarms Pressurisation alarm This alarm indicates that the temperature has not increased properly in chamber 09 during the steam phase (steam or pressurisation peaks). The steriliser may display this alarm during a cycle, during steam phases, when the pressure does not correspond to the saturated steam curve. •...
  • Page 35: Sterilisation Temperature Band Alarm: Overtemperature / Undertemperature

    Alarms Sterilisation temperature band alarm: overtemperature undertemperature Both alarms indicate that the temperature is out of the sterilising band (tolerance) defined by EN 13060. This standard defines the tolerance band (0°C - +4°C) from the setting value during sterilization. For example, if the setting is 134°C, the temperature should be in the band 134°C-138°C.
  • Page 36: Level Probe Alarm

    Alarms 3. Replacing the PT1 temperature probe - Replace chamber temperature probe 39. - Select option 3 in the Technician Menu (Board calibration PT1 page 12) and proceed with calibration. - Select option 3 in the Technician Menu (PT1 Probe calibration page 15) and enter the R0 value.
  • Page 37: Self-Filling Alarm

    Alarms Unlocking tool 37 must be fully inserted. Open the door without forcing it, remove unlocking tool 37 and open the handle completely. • Check the coils with a tester for continuity without checking the value. • Check TRIAC components on power board 34 and replace the electronic board pair, if required.
  • Page 38: Door Alarm

    Alarms • In configuration (B), check that the water supply tap is open and that the mains water pressure is higher than the minimum pressure indicated for the installed demineralisation system. • If the problem persists, check if solenoid valve EV7 opens correctly. In both cases, check: - that all connections are properly connected;...
  • Page 39: Pt1 Temperature Probe Alarm

    Alarms Micro-switch M2 36B: PT1 temperature probe alarm This is triggered when chamber temperature probe 39 in the steriliser is disconnected or faulty. The steriliser shows this alarm during operation when the probe detects a temperature of less than 3°C. •...
  • Page 40: Pressure Transducer Alarm

    - mains blackout; - power cable 03 not plugged in correctly or damaged; - blown fuses 32. Event alarm This indicates that one of the timed phases (sterilisation, drying or vacuum test hold) was not completed correctly. • Contact COMINOX.
  • Page 41: Alarm Code List

    Alarms Alarm code list Code Alarm type COIL OVERTEMPERATURE PT1 INSUFFICIENT STEAM INSUFFICIENT WATER LEVEL MAX WATER LEVEL DOOR MANUAL STOP INSUFFICIENT VACUUM FRACTIONED VACUUM LEVEL PROBE PRESSURISATION OVERTEMPERATURE BAND UNDERTEMPERATURE BAND POWER MISSING DRAIN MISALIGNMENT PRESSURE TRANSDUCER PT1 TEMPERATURE PROBE EVENTS...
  • Page 42: Additional Checks And Settings

    Additional Checks And Settings ADDITIONAL CHECKS AND SETTINGS Display off or not clear Proceed as follows if no writing appears on the display and/or any if the display is not very clear: • Check that power socket is powered, the power cable 03 is correctly plugged in and connected to the steriliser.
  • Page 43: Safety Valve Check

    Additional Checks And Settings If messages and alarm appear after emptying the tanks, remove the probes and clean the probes carefully as follows: - Remove the cover and the faston (A) from the probe bulb. - Use a wrench ch 13 to loose the probe holder (B) and remove the probe rod.
  • Page 44: Door Adjustment

    Additional Checks And Settings Door adjustment • Procedure for 18/24 litre models: if leakages still occur after checking and cleaning chamber seal 31 and the flange of chamber 09 on which it rests, you will need to: - Switch the steriliser off and wait for it to cool down, then open the door. - Use a wrench ch5 to loosen the screw inside the hole on the left side of the door.
  • Page 45: Pressure Rises Too Slowly

    Additional Checks And Settings Water in the chamber after the cycle Proceed as follows if there is still water inside chamber 09: • Check that a cycle with drying phase has been selected. Otherwise, the presence of water or humidity in the chamber is a normal condition. •...
  • Page 46: Vacuum Pump Servicing Procedure

    Additional Checks And Settings Vacuum pump servicing procedure The vacuum pump can be serviced by cleaning it and replacing the seals which are supplied in the specific kit. Proceed as follows for vacuum pump 2119: • Remove the pump and carefully check the position of components.
  • Page 47 Additional Checks And Settings Proceed as follows for vacuum pump 41 B: • Remove the pump and carefully check the position and orientation of components. • Check that membrane C, valves D and O- Rings are not damaged. clean them or replace them if required.
  • Page 48: Water Automatic Inlet Does Not Work Correctly

    Additional Checks And Settings Water automatic inlet does not work correctly Proceed as follows if the automatic water inlet 29 optional) is not working correctly: • Check that this device is actually available because not all models are supplied with the automatic water inlet. •...
  • Page 49: Automatic Water Inlet And Direct Drain System Installation

    Automatic filling Automatic water inlet and direct drain system installation This accessory may be fitted after installing the steriliser and it includes both the automatic water inlet 29 and direct drain system 30. These systems are the same for all models: only the tube length and arrangement changes.
  • Page 50 Automatic filling • Fit the automatic water inlet pump 46 correctly blocking it on its support. • Fit the branches (Y) and all connecting pipes. • Fit the external filling and drain pipes; the end of the inlet pipe is cut in a particular manner to prevent a suction effect when it rests on the bottom of the tank.
  • Page 51: Installation Of The Speedy Water Demineralization System

    Speedy Water Installation of the SPEEDY WATER demineralization system The SPEEDY WATER demineralization system should be used to connect the SterilClave 6/18/24 sterilisers to the mains water in automatic water inlet configuration B (see USER AND MAINTENANCE MANUAL, chapter CONNECTIONS). The SPEEDY WATER demineralization system consists of: •...
  • Page 52 Speedy Water Installation of the SPEEDY WATER demineralization system To install the SPEEDY WATER demineralization system on a steriliser already fitted with automatic water inlet 29 and direct drain 30, follow these steps: • Install support bracket A to a wall suitable to hold the weight of the plate and of the purification block B during operations (5.6 kg).
  • Page 53 Speedy Water • Replace the automatic water inlet pump 46 and the connection pipes with the solenoid valve EV7 (mounted on its support and with the outlet hose holders and the inlet L-joint) and the pipes supplied. Use the teflon pipe to connect the internal joint on the back of the steriliser with the solenoid valve EV7 (inlet 1) and use the silicone pipe to connect the solenoid valve EV7 (outlet 2) to the clean water tank 10: •...
  • Page 54: Sterilcard Reader Installation

    SterilCard reader SterilCard reader installation The SterilCard kit includes: • Administrator and User SterilCard • SterilCard reader • SterilCard reader support • Cable • 4 self-tapping screws • 4 spacers • 4 M3x6 screws • 4 nuts • 8 washers Follow these instructions to assemble the SterilCard kit: 1.
  • Page 55 SterilCard reader 2. Mount the assembly in the control panel with the 4 self-tapping screws as shown in the picture. Note: The assembly must be placed as high as possible, so that the opening of the control panel is aligned with the one of the SterilCard reader. 3.
  • Page 56: Printer Installation

    Printer Printer installation If the set up of the printer 26 (optional) takes place following the purchase of the steriliser, a specific kit is provided. To install the components follow the procedure described below. Note: This procedure is flexible. For this reason, keep track of the removal sequence for re- establishing the correct operating conditions.
  • Page 57 Printer • Fit the frame (C) on the control panel (P) with the four screws previously removed from the lid (R). • Connect the printer cable (L) to connector CN2 of the printer. • Insert the printer into the frame (C) and make the fastening side tabs snap.
  • Page 58 Printer • Connect the printer cable (L) to connector CN6 on power board 34: • In the Technician Menu, scroll to Accessories (option 16), set Printer ON and check operation. Close and reinstall the steriliser.
  • Page 59: Firmware Upgrade

    Firmware upgrade Firmware upgrade To upgrade the firmware file, the configuration file and the parameters file, follow these steps: 1. Connect the steriliser to the computer using the USB serial cable. 2. Turn on the sterilizer from the main switch 13. 3.
  • Page 60: Diagrams And Wirings

    Diagrams and wirings DIAGRAMS AND WIRINGS Logic electronic board Logic board 33 is a low voltage board common to all models. Connection cable to power board 34 Connection cable to the serial port Connection cable to the SterilCard reader Connection cable to the keyboard Display adjustment trimmer (see chapter DISPLAY OFF OR NOT CLEAR)
  • Page 61: Electronic Power Board

    Diagrams and wirings Electronic power board The power board 34 is common to all models. Connection cable to logic board 33 Load connector: 1 - Solenoid valve EV1 and water inlet pump 35 [orange] 2 - Water drain solenoid valve EV2 [brown] 3 - Three-way solenoid valve EV3 [pink-black] 4 - Steam solenoid valve EV4 [green] 5 - By-pass solenoid valve EV5 [purple]...
  • Page 62 Diagrams and wirings FUSES 16 A 10 A 0.63 A Internal coil on LED +5V power LED External coil on LED Coil safety LED (on in normal conditions, off when a COIL ALARM occurs) Printer power LED +24V power LED...
  • Page 63 Diagrams and wirings...
  • Page 64: Wiring Diagram - 18/24 S - B - Bhd

    Diagrams and wirings Wiring diagram - 18/24 S - B - BHD EV... Solenoid valves Water inlet pump 35 Door lock winding Automatic water inlet pump 46 (config. A), solenoid valve EV7 (config. B) Power contactor Safety pressure switch Anti-jamming filter Vacuum pump 41 Fuses 32 Drying coil...
  • Page 65: Wiring Diagram 6 S Dynamica

    Diagrams and wirings Wiring diagram 6 S Dynamica EV... Solenoid valves Water inlet pump 35 Door lock winding Automatic water inlet pump 46 (config. A), solenoid valve EV7 (config. B) Power contactor Safety pressure switch Anti-jamming filter Vacuum pump 41 Fuses 32 Upper coil Fans 42...
  • Page 66: Wiring Diagram - 18 S Dynamica

    Diagrams and wirings Wiring diagram - 18 S Dynamica EV... Solenoid valves Water inlet pump 35 Door lock winding Automatic water inlet pump 46 (config. A), solenoid valve EV7 (config. B) Power contactor Safety pressure switch Anti-jamming filter Vacuum pump 41 Fuses 32 Drying coil Fans 42...
  • Page 67: Hydraulic Diagram 18/24 S - B - Bhd

    Diagrams and wirings Hydraulic diagram 18/24 S - B - BHD EV... Solenoid valves Clean water drain tap 24 Condenser Waste water drain tap 25 Air sterilisation filter 15 Direct drain (BHD model only) Water inlet pump 35 Clean water tank 10 Automatic water inlet pump 46 (config.
  • Page 68: Hydraulic Diagram 6/18 S Dynamica

    Diagrams and wirings Hydraulic diagram 6/18 S Dynamica EV... Solenoid valves Clean water drain tap 24 Condenser Waste water drain tap 25 Air sterilisation filter 15 Direct drain Water inlet pump 35 Clean water tank 10 Automatic water inlet pump 46 (config. A), solenoid valve EV7 (config. B) Waste water recovery tank 11 Transducer 38 (pressure) Safety pressure switch...
  • Page 69: Steam Peak Diagram

    Diagrams and wirings STEAM PEAK diagram P1, EV1 ON until the water reaches the chamber level probe EV2 ON Internal coil ON Water is vaporised inside the chamber...
  • Page 70: P>1,2 Bar Vacuum Pulse Diagram

    Diagrams and wirings p>1,2 bar VACUUM PULSE diagram Pressure inside the chamber is higher than the atmospheric value Steam flows naturally...
  • Page 71: P<=1,2 Bar Vacuum Pulse Diagram

    Diagrams and wirings p<=1,2 bar VACUUM PULSE diagram EV3 ON EV6 ON PV ON Steam/air removal from the chamber EV2/EV3 cycle introduces air in the pump and removes condesed steam...
  • Page 72: Drying Diagram

    Diagrams and wirings DRYING diagram EV3 ON EV6 ON PV ON Moreover EV5 is periodically ON Steam removed from the chamber is replaced by filtered air...
  • Page 73: Appendix 1: 18/24 Cycle Set Points

    Appendix 1 APPENDIX 1: 18/24 CYCLE SET POINTS 18/24 B - BHD CYCLE SET POINTS Sterilis Pre- Steam Vacuum Drying Sterilisation ation Drying Drying vacuum peak pulse temperature temper pressure length pressure pressure pressure pressure (°C) ature (mbar) (min) (mbar) (mbar) (mbar) (mbar)
  • Page 74: Appendix 2: Coldest And Warmest Point Definition

    Appendix 2 APPENDIX 2: COLDEST AND WARMEST POINT DEFINITION Coldest point SterilClave 18/24: n° 5 Warmest point SterilClave 18/24: n° 6...
