- Page 1 Wall Mount Models: 2500 Installation, Operation and Maintenance Instructions Please read all instructions before attempting installation or operation of these units SAVE THESE INSTRUCTIONS FOR FUTURE USE Revised UBLICATION 5 0 1 7 5 2 9 3 7 October 16, 2009...
-
Page 2: Table Of Contents
2500 Wall Mount TABLE OF CONTENTS Section Page No. Introduction Notice to Installers Cautions and Warnings Model Information Parts List Kits List (Kits contained within the Parts List) Tools Required Wood Pad Installation Special Bracket Considerations Unit Installation Operation Guidelines... -
Page 3: Introduction
2500 Wall Mount INTRODUCTION Thank you for your purchase of a Model 2500 Wall Mounted Backstop. To ensure that our equipment will provide years of use to you, we are including this installation, operation, and maintenance guide. This guide will provide information on the proper assembly and installation methods, operating procedures, and preventative maintenance of your wall mounted backstop. -
Page 4: Notice To Installers
If materials or parts are determined to be missing due to factory error or oversight, contact Gared/PSS immediately at 800-325-2682/ 800-848-8034. Follow all local safety codes and OSHA regulations. Gared/PSS will not be held liable, in any way, for improper installation or faulty workmanship at the jobsite. -
Page 5: Cautions And Warnings
2500 Wall Mount CAUTIONS AND WARNINGS Read and understand the following warnings to prevent possible personal injury and potential damage to the equipment during assembly, setup, and operation. -
Page 6: Model Information
2300 – 4 point stationary 2350 – 3 point stationary 2400 – 4 point fold up 2500 – 4 point side fold EXTENSION 203 – 2’ to 3’ (see installation drawings for exceptions) 304 – 3’ to 4’ (see installation drawings for exceptions) 406 –... -
Page 7: Parts List
STRAP BRACING, 78" (WIDE FRAME) 504151670 4 ea STRAP BRACING, 48" (NARROW FRAME) 504151672 4 ea STRAP BRACING, 69" (WIDE FRAME) 2500 SIDE FOLD WALL MOUNT - WOOD PADS FRAME SIZE PART NUMBER: QTY: DESCRIPTION: 504151591 3 ea WOOD PAD, 3.5" HC, 48"... -
Page 8: Kits List (Kits Contained Within The Parts List)
2500 Wall Mount KITS LIST HARDWARE KIT, WALL MOUNT UNITS PART NO. 154151696 QTY. PART NO. DESCRIPTION 1000-26-00 BANK BOLT HARDWARE KIT 1001-26-00 GLASS BOARD GOAL BOLT KIT 501-6-16-56 BOLT, CARRIAGE 3/8"x 3 1/2" 502-6-16-56Z BOLT, HEX HEAD 3/8"-16 x 3 1/2"... - Page 9 2500 Wall Mount SIDE FOLD ADDER KIT PART NO. 154151702 QTY. PART NO. DESCRIPTION 1030-02-08 LOCKING CLAMP, SIDE SWING WALL MOUNT 151651768 KIT, #116 TEE CLAMP 2183-02-00 #0183 - 1 7/8" TO 2 3/8" 501651854 SPACER BUSHING, 2 1/8" TO 2 3/8"...
- Page 10 2500 Wall Mount KIT, FAN BOARD TO AAG PART NO. 153954405 QTY. PART NO. DESCRIPTION 1000-26-00 BANK BOLT HARDWARE KIT 502-6-16-16 BOLT, HEX HEAD 3/8"-16 x 1" 501-6-16-56 BOLT, CARRIAGE 3/8"x 3 1/2" 502-6-16-56Z BOLT, HEX HEAD 3/8"-16 x 3 1/2"...
-
Page 11: Tools Required
2500 Wall Mount TOOLS REQUIRED Electric Drill Drill bits – 9/16”, 5/8” Hammer Wrenches – 1/2", 9/16”, 11/16, and 3/4" Ratchet Wrenches with 1/2", 9/16”, 11/16, and 3/4" sockets File 4’ Level 25’ Tape measure Duct Tape Block of wood (for tapping) -
Page 12: Wood Pad Installation
2500 Wall Mount WOOD PAD INSTALLATION Instructions for 2500 Side Folding Wall Mounts 1) Wood pads are provided for use in anchoring the units to the walls. 2) Verify all dimensions and locations with the General Contractor using the latest architectural prints before beginning. - Page 13 2500 Wall Mount NOTE: Wood pad dimensions for reference only. See production drawing for final A, B, and C dimensions. If production drawing cannot be located please contact the factory. UNITS INSTALLED WITH OR WITHOUT AAG ALL UNITS DIM "B"...
-
Page 14: Special Bracket Considerations
2500 Wall Mount SPECIAL BRACKET CONSIDERATIONS Use the figures above to set up your hardware to match the direction of fold desired. Check with the General Contractor or Architect to confirm correct direction of fold. Note the placement of the cross brace pipe hinge as shown in the detail below. -
Page 15: Unit Installation
2500 Wall Mount UNIT INSTALLATION 1) Prepare the extension tubes by inserting bushings as shown in figure 3. Figure 3. Bushing installation (side view) 2) To attach the outer extension tubes to the wall brackets, use a hex bolt and nylon lock nut as indicated on the installation drawing. - Page 16 2500 Wall Mount Wide Narrow Figure 4. Attach AAG mounting frame to extension tubes. 6) Connect the chains from the upper wood pad to the board mounting plate, utilizing the quick links provided. 7) At this point, it is equally acceptable to attach the board or hoist the adjust-a-goal into place at the end of the extension arms.
- Page 17 2500 Wall Mount 10) To permanently set the length of the extension arms, drill 3/8” holes through the inner tube at the predrilled location on the outer extension arms. Secure the inner tube to the outer tube with the provided hex head bolts and lock nuts (3/8”- 16x 2 ½”).
-
Page 18: Operation Guidelines
2500 Wall Mount #116 t-clamp Figure 7. Bracing pipes for side fold units installed between upper and lower pipes. 16) Retighten the chains. OPERATION GUIDELINES 1) For all folding backstops, only a trained adult should operate the m anual and electric winches. -
Page 19: Maintenance
2500 Wall Mount MAINTENANCE 1) General inspection of equipment should be performed when the unit is used to ensure no catastrophic failures have occurred during the course of use between yearly inspections. 2) It is recommended that yearly inspections be conducted to determine if any bolts, chain links, or other hardware has become worn or loosened. -
Page 20: Maintenance Checklist
2500 Wall Mount MAINTENANCE CHECK SHEET Date:________________ Unit:___________________ Wood Pads / Anchors -Wood pads, splitting, chipping, etc. Repair Replace -Anchors/Bolts Repair Replace Unit Supports / Brackets / Hinges -Tubes; dents, stress spots, etc. Repair Replace -Bolts; loose, deformed, etc. Repair Replace -Brackets/Hinges;... - Page 21 Gared Holdings, LLC Performance Sports Systems Gared Sports 9200 E. 146 Street 707 North 2 Street Noblesville, IN 46060 St. Louis, MO 63102 800-848-8034 800-325-2682 www.perfsports.com www.garedsports.com...
