MALIBU 2 SEAT SWING
Assembly Instructions - Please keep for future reference
Dimensions
Width - 153cm
Depth - 120cm
Height - 162cm
Important - Read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456400800
For further assistance please visit http://www.argos-support.co.uk/
6503501
Issue 1 - 24/10/16
Advertisement
Table of Contents
Related Manuals for Argos MALIBU 2 SEAT SWING 6503501
Summary of Contents for Argos MALIBU 2 SEAT SWING 6503501
- Page 1 Depth - 120cm Height - 162cm Important - Read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456400800 For further assistance please visit http://www.argos-support.co.uk/ Issue 1 - 24/10/16...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly Always remove the canopy in Check you have all the Assemble on a soft level components and tools listed on heavy wind conditions, otherwise surface to avoid damaging the the canopy may tip over and pages 2 &... - Page 3 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. M8 x 75mm Bolt x 4 M6 x 50mm Bolt x 10 M6 x 45mm Bolt x 8 ST4.2 x 16mm Screw x 4 D17 Washer x 8 D16 Washer x 28...
-
Page 4: Components - Parts
Components - Parts Please check you have all the parts listed below Top Cross Beam x 1 Front Upright Support x 2 Rear Upright Support x 2 Rear Cross Brace x 1 Lateral Cross Brace x 2... - Page 5 Components - Parts Please check you have all the parts listed below Right Seat Arm x 1 Left Seat Arm x 1 Seat Assembly x 2 Swing Arm Tube x 4 Front/Rear Canopy Brace x 2 Side Canopy Brace x 2 Support Brace x 2 Canopy x 1...
-
Page 6: Frame Assembly
Assembly Instructions Step 1 FRAME ASSEMBLY Note: When fastening with bolts and nuts, always use washer the tube and the bolt or the tube and the plastic nuts. Fasten the front and rear upright supports the top by using two sets of bolts , washers spring washers... -
Page 7: Seat Assembly
Assembly Instructions Step 2 SEAT ASSEMBLY Connect right seat arm left seat arm together by using support braces . See Figure for correct position of support braces NOTE: The labels marked “L” and “R” on the seat arms should coincide with Figure to ensure proper assembly. -
Page 8: Attach Canopy
Assembly Instructions Step 5 Hook the suspension springs into the top of both swing arm tubes . Repeat both sides. Hang the opposite ends of the suspension spring into the holes located on the angled braces of the top cross beam Repeat both sides. - Page 9 Assembly is completed. If you need help or have damaged or missing parts, call the Customer Helpline: 03456400800 For further assistance please visit http://www.argos-support.co.uk/ Retailer: Argos Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9, 2NW...
