9x4M Gazebo With 4 Side Panels
Simple Assembly Instructions
Dimensions
Width - 400cm
Depth - 900cm
Height - 320cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: Argos = 0345 6400800
For further assistance please visit http://www.argos-support.co.uk
Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks,MK9, 2NW
- Please keep for future reference
652/2719
Issue 1 - 13/09/13
Advertisement
Related Manuals for Argos 652/2719
Summary of Contents for Argos 652/2719
- Page 1 – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 For further assistance please visit http://www.argos-support.co.uk Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks,MK9, 2NW...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Important – Please read these instructions fully before starting assembly • Follow all safety and fire • Check you have all the Positioning: precautions when in or near components, fittings and tools • To prevent the wind blowing this Gazebo. - Page 3 Components - Parts & Fittings If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the parts listed below 1 x Roof 2 x Side panel 2 x End Panel...
- Page 4 Assembly Instructions Stage 1 – Assembling the connecting frames Step 1 1.Fully insert Support Pole into the Centre joint and Corner Joint . Then use Wing Screws to fix the Centre Joint Corner Joint onto the Support Pole See fig.1. Fig.1 Step 2 Use the same method...
- Page 5 Assembly Instructions Stage 2 – Fitting the connecting frames Step 3 Fully insert Top Poles into one of the connecting frames. Then use Wing Screws to fix the Top Pole in the unit. See fig.4. Fig.4 Step 4 Firmly fit the other two connecting frames to the unit.
- Page 6 Assembly Instructions Stage 3 – Fitting the Roof Step 5 Carefully locate the Roof on top of the unit. Then use Canopy Ties to fix the Roof onto the unit. See fig.6. Fig.6 Step 6 Unscrew the Nut and Screw from the Base Plate See fig.7.
- Page 7 Assembly Instructions Stage 4 – Fitting the Leg Poles Step 7 Use Wing Screws fix 5 Leg Poles one side of the unit. See fig.8. Use the same Canopy Ties as before to fix the top of the End Panels onto the unit.
- Page 8 Assembly Instructions Stage 5 – Fitting the Side Panels Step 9 Use the same Canopy Ties as before to fix the top of the Side Panels onto the unit. See fig. 11. Use the Velcro tapes on the Side Panels End Panels to fix them on the Leg Poles.
- Page 9 Gazebo. Fig.22 If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 For further assistance please visit http://www.argos-support.co.uk Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks,MK9, 2NW...
