  • Page 1 A Ham Radio Deluxe Sponsor www.g4zlp.co.uk DigiMaster DataLink DATA interface...
  • Page 2 You may need also need to refer to instructions that relate to the specific DATA lead that you use to connect the interface to your radio. For example, your radio may need certain parameters setting when using a radios 6 pin mini din socket. When using other cables, your radio may need other settings to be made.
  • Page 3 DigiMaster DataLink Interface. Simple 3 step setup procedure [1] Configure DM780 to use the new soundcard. [2] Configure DM780 to allow the soundcard to activate the radios PTT. [3] Configure Windows volume controls for optimum performance. [1] Configure DM780 to use the USB audio CODEC (soundcard in the DataLink interface).
  • Page 4 [2] Configure DM780 to allow the soundcard to activate the radios PTT. Open DM780’s program option window (F8). In the PTT “None” section, select;- Select “via soundcard PTT. The interface will automatically generate the PTT signal. DO NOT ACTIVATE YOUR RADIOS VOX. The PTT is generated by the interface and to avoid unexpected results it is important that you turn your radios vox off.
  • Page 5 [3] Adjusting the soundcard input and output levels. First check any instructions that may be applicable to use the DATA lead to your radio. For example there are instructions when using a “UN01” DATA lead that tells you to set your radios packet baud rate to 1200.
  • Page 6 The following window will open;- Double click the “USB audio CODEC” which will open another window;- You should also bear in mind that many radios have adjustments that can be made to change input and output levels (or gain), some radios can be adjusted by the radios menu system. It is important that you leave the Windows balance control at the centre position.
  • Page 7 When using DATA interfaces, many users (mistakenly) set the power output on the radio and overdrive the radio with a strong signal from the DATA interface and end up with a poor TX signal or high ALC... An easy way to set and get a good TX signal is as follows; [a] Set your radio’s power control to maximum.
  • Page 8 If you have multiple DataLink interfaces connected to your PC then Device manager will show each codec; If you run several instances of DM780 then each should be configured to use one of the codecs, note that DM780 numbers them for you. Although you can run many instances of HRD there is no provision in DM780 (at time of writing) to save multiple configurations as “profiles”...

  • Page 9: In Case Of Problems

    In case of problems: LED switches from GREEN to RED when operating software to TX. Some radios may go into TX but send no DATA. Some radios will not go into TX. Some radios such as Icom 706 require baud rate to be set at 1200. This selects the appropriate pin on the 6 pin DATA socket for PTT (1200 rather than 9600).
