- Page 1 IMPORTANT: Read before Using P2LC15S CROSS LINE LASER LEVEL WITH PLUMB POINTS LIMITED www.prexiso-eu.com WARRANTY YEARS...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Working safely with the measuring tool is possible only when the operating and safety information are read completely and instructions contained herein are strictly followed. Never make warning labels on the measuring tool unrecognizable. SAVE THESE INSTRUCTIONS. Caution – The use of operating or adjusting equipment or the application or processing methods other than those mentioned herein, can lead to hazardous radiation exposure. -
Page 3: Techinical Specifications
• Keep the tool away from cardiac pacemakers. The magnet inside the tool generates a field that can impair the function of cardiac pacemakers. • Keep the tool away from magnetic data medium and magnetically-sensitive equipment. The effect of the magnetic can lead to irreversible data loss. •... - Page 4 DESCRIPTION CROSS LINE LASER LEVEL WITH PLUMB POINTS This self-leveling cross line laser is a highly versatile tool. It can be placed on the ground, mounted on a door frame or work bench etc.when use the appropriate accessories eg. magnetic mounting bracket, tripod(not included) etc. but not limited.
-
Page 5: Product Overview
DESCRIPTION PRODUCT OVERVIEW Figure A - Laser Tool 5. Battery Cover 1. Keypad 6. 5/8 - 11 Threaded Mount 2. Window for Vertical Beam Laser 7. Window for Down Beam Laser 3. Window for Horizontal Beam Laser 8. 1/4 - 20 Threaded Mount 4. - Page 6 PRODUCT OVERVIEW Figure B - Laser Tool Battery Location 1. Battery Cover 2. Batteries - 3 x “AA” (LR6) (Included) Figure C - Pendulum / Transport Lock Positions Figure D - Keypad Configurations Figure E - Laser Modes Figure F - Pulse Mode KEYPAD, MODES, AND LED Keypads (See figure D) Power ON / OFF / Mode Key...
- Page 7 UNPACKING When unpacking the box, do not discard any packing materials until all of the contents are accounted for: • Self-Leveling Cross Line Laser Tool • Magnetic mounting bracket • bag • 3 x AA alkaline batteries • Operator’s manual Carefully lift the compact laser measuring tool out of the package and place it on a stable, flat surface.
-
Page 8: Operation
CAUTION: Do not leave the laser tool unattended on an accessory without fully tightening the fastening screw. Failing to do so may lead to the laser tool falling and sustaining possible damage. NOTE: It is best practice to always support laser tool with one hand when placing or removing laser tool from an accessory. -
Page 9: Maintenance
APPLICATIONS The self-leveling cross line laser can be placed on the ground, mounted on an iron work bench / door frame etc. for point marking and simple alignment by sight, It is ideal for the following applications: • Hanging pictures, photos, or artwork on walls •... -
Page 10: Warranty
Product specific treatment and waste management can be downloaded from our homepage. WARRANTY The Instrument P2LC15S has a two-year warranty. For further information on this, contact your dealer. This warranty is void if product is used for commercial purposes. This...
