Summary of Contents for Merax Z1Z-CF02-80

  • Page 2 1. Safety Instructions: Warning! When using tools, read safety instructions carefully. 2. Safety instructions: 2.1. Ground wiring: Warning! Check if power supply to be used is accordingly grounded. Electric lines: Use electric line with standard ground wiring to avoid the ristl of electric shock and damage equipment, including accessories.
  • Page 3 PHOTO 1 PHOTO 2 2.7. Before reviewing or changing the drill bit of your Diamond Core Drill, the power supply must be off. 2.8. Store the tools in a dry place when you were not using them. 1. Fastening your Diamond Core Drill There are three ways of fastening your Diamond Core Drill: 1.1.
  • Page 4 1.2. Use a stripper (metal pipe, etc.) to help you. Secure this stripper between the roof and the regulation screw on the top of the Diamond Core Drill stand (photo). Torque the screw until the stripper touches the roof, securely fastening the Diamond Core Drill.
  • Page 5 After the machine security fastened, level it using the four screws located on the ends of the base Lock them using the lock screws. 2. Installing diamond core bits on your Merax Diamond Core Drill. Grease the thread of the diamond core bits. Insert it and fasten it lightly. Turn the machine on and let the drillbit turn freely to make sure everything is working properly.
  • Page 6 The Diamond Core Drill has an automatic shutdown system in case of current overload or drillbit lockup. Do not try to force the machine to work and tryi to identify what is causing the problem. Inadequate use can severely damage the tool.
  • Page 7 6. WARRANTY: MERAX Diamond Core Drillsv have a 6-month guarantee in Brazil after the date of issue of invoice or delivery of the product to the final consumer. This warranty applies to manufacturing, materials, parts and workmanship defects, when adequately proven.

This manual is also suitable for:

Z1z-cf02-205Z1z-cf02-255
