Premier Mounts Convergent Series Installation Manual

Video wall mount for samsung if h led cabinets
Hide thumbs Also See for Convergent Series:

Advertisement

Quick Links

Download this manual
SERIES: SAM IF(H)
INSTALLATION GUIDE
Convergent Series Video Wall Mount
For Samsung IF(H) LED Cabinets
9500255 v1.2
publ. 07/21/20

Advertisement

loading
Need help?

Need help?

Do you have a question about the Convergent Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Premier Mounts Convergent Series

Summary of Contents for Premier Mounts Convergent Series

  • Page 1 SERIES: SAM IF(H) INSTALLATION GUIDE Convergent Series Video Wall Mount For Samsung IF(H) LED Cabinets 9500255 v1.2 publ. 07/21/20...

  • Page 2: Caution Statements

    4. ALL LED CABINETS MUST BE POWER ON TESTED PRIOR TO ANY INSTALLATION. 5. PREMIER MOUNTS RECOMMENDS THE HANDLING LED CABINETS BY AN INDUSTRY QUALIFIED PROFESSIONAL. 6. PREMIER MOUNTS IS NOT RESPONSIBLE FOR DEFECTS, MISUSE, OR IMPROPER HANDLING OF THE LED CABINETS. Tools for Installation: 00.0...
  • Page 3 SAMSUNG IF (H) - Installation Guide VIDEO WALL DIMENSIONS AND MOUNTING LOCATIONS OVERALL WIDTH Available Rail Size X OVERALL HEIGHT LASER LEVEL The overall dimensions of any video wall array can be Available Imperial Metric calculated by using the table within this page. Size (Inches) (Milimeters)
  • Page 4 - SAMSUNG IF (H) Installation Guide ITEM #. PART NO. DESCRIPTION 4000-300-221-LX Vertical Right End Rail 2V 4000-300-212-LX Horizontal Rail 2H 4000-300-222-LX Vertical Center Rail 2V 4000-300-213-LX Horizontal Rail 3H 4000-300-223-LX Vertical Left End Rail 2V 4000-300-218-LX Vertical Right End Rail 1V 4000-300-231-LX Vertical Right End Rail 3V 4000-300-219-LX...

  • Page 5: Pre-Installation

    SAMSUNG IF (H) - Installation Guide PRE-INSTALLATION Floating Adjustment Assembly (or “Floaters”) M6 x 35mm Socket Screw Nylon Washer Steel Washer ±1/4” adjustment from neutral position M5 x 10mm Comb Screw To keep the flange straight at all times. DO NOT REMOVE. 1.

  • Page 6: Assemble The Frame

    - SAMSUNG IF (H) Installation Guide ASSEMBLE THE FRAME Horizontal Rail Vertical Rail (Left) (4) M5 x 8mm Flat Head per Vertical Rail (Right) Vertical Rail (center) All configurations require the left and right vertical rail brackets mounted at the ends of the entire array with the “center”...
  • Page 7 SAMSUNG IF (H) - Installation Guide Install a few support screws to hold the mount roughly near the desired location. Place a level on top of the mount and readjust the support screws if necessary. Secure the first mounting location by sliding a Wall Anchor Plate behind the mount and fasten using 1/4”...
  • Page 8 - SAMSUNG IF (H) Installation Guide Multiple Unit Configuration Extend Horizontally To extend the width of the unit, follow the steps below. 1. Hang and position the second Horizontal Rail side by side. 2. Place a support screw while maintaining a leveled horizontal rail to temporary hold in place. 3.
  • Page 9 SAMSUNG IF (H) - Installation Guide Multiple Unit Configuration Extend Vertically To extend the height of the unit, follow the steps below. Place the rail brackets directly above or below the another rail brackets as shown. Use the Attachment Plates to unite the two rail brackets together. Fasten using (2) M5 x 8mm Flat Head Screw per.
  • Page 10 - SAMSUNG IF (H) Installation Guide SQUARE AND LEVEL Inspect each bracket using a Square and Level tool. FINETUNE THE RAIL FOR FLATNESS 1. Install wherever possible. 2. Use drywall or wood screws to pull the brackets towards the wall. 3.

  • Page 11: Very Important

    SAM IF(H) - Installation Guide VERY IMPORTANT! VERIFYING THE DIAGONAL MEASUREMENTS FOR SQUARENESS Distance 1 The two diagonal measured distances must match Distance 2 Measure the distance from corner to corner with a measuring tape. Measure diagonally opposite and verify the diagonal measurements. Proceed only if the two measurements are equivalent.
  • Page 12 - SAMSUNG IF (H) Installation Guide VERIFYING THE MOUNT FOR FLATNESS 1. Tie a string from one end to the other end of the entire array. 2. Tie horizontally and crisscross, especially for large video wall array. 3. Inspect for any gaps between the brackets and the string. 4.
  • Page 13 SAMSUNG IF (H) - Installation Guide USE ADDITIONAL MOUNTING SLOT TO SECURE THE FRAME NOTES: If using the additional slots for mounting points, make sure that the floating frame is fully level to the wall vertically and horizontally. Must use shims (commercially available) on every slots being used to fill the void between the wall and the frame.
  • Page 14 - SAMSUNG IF (H) Installation Guide SAMSUNG IF LED DISPLAY INSTALLATION MANUAL must be read in conjunction with the recommended steps below. LED Cabinets to be handled by industry qualified professional. Improper installation may cause damage to the LEDs. 1. Install the first LED Cabinet from the center bottom row of the mount.
  • Page 15 2. Slowly slide the Gap-It tool away from the LED Cabinets while lowering into place. See Figure 2. PREMIER MOUNTS IS NOT RESPONSIBLE FOR ANY IMPROPER HANDLING OF THE LED CABINETS. Cautionary Advice: Do not damage the LEDs when lowering.
  • Page 16 - SAMSUNG IF (H) Installation Guide IMPORTANT: SECURE THE LED MODULES The LEDs must be perfectly installed without any noticeable seams, black bars, or imperfection of the LED modules. Modules must be in locked position before moving forward. 1. Install the PET Sheet around the boundary of the entire video wall array as shown below.
  • Page 17 SAMSUNG IF (H) - Installation Guide Page 17...
  • Page 18 - SAMSUNG IF (H) Installation Guide Page 18...
