Analog HD Video Capture Device
Model 2431
Hardware Manual
Ver. 1.0.0 | March 2020
SENSORAY | p. 503.684.8005 | email:info@SENSORAY.com | www.SENSORAY.com
7313 SW Tech Center Drive | Portland, OR 97203

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2431 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sensoray 2431

  • Page 1 Analog HD Video Capture Device Model 2431 Hardware Manual Ver. 1.0.0 | March 2020 SENSORAY | p. 503.684.8005 | email:info@SENSORAY.com | www.SENSORAY.com 7313 SW Tech Center Drive | Portland, OR 97203...
  • Page 2: Table Of Contents

    Table of Contents Limited warranty ......................... 3 Introduction ..........................4 System Requirements ........................5 Software interface ........................6 Connectors ............................ 7 Video inputs - JP1........................7 Audio inputs – JP2 ........................7 Power – JP3 ..........................8 MicroSD card extension, JP5 ....................8 RS232, USB host, I2C –...
  • Page 3: Limited Warranty

    Sensoray specifications for two years from the date of shipment to purchaser. Sensoray will, at its option, repair or replace equipment that proves to be defective during the warranty period. This warranty includes parts and labor.
  • Page 4: Introduction

    Introduction Model 2431 captures video from analog HD and SD video sources. It has an Ethernet interface. It will overlay and compress resolutions up to 1080p30. Audio can be extracted from the SDI data, or captured from a microphone or line source.
  • Page 5: System Requirements

    System Requirements Model 2431 requires a 100Base-TX Ethernet connection. The default Ethernet address is 192.168.24.64, net mask 255.255.0.0.
  • Page 6: Software Interface

    Software interface The 2431 is programmable via Ethernet using HTTP (TCP port 80). Setting a configuration parameter uses the POST method, and getting the current value uses GET method. Each parameter has a level of access control, and if user privileges are enabled on the device, Digest Authentication should be used to provide the username and password.
  • Page 7: Connectors

    Connectors Video inputs - JP1 Molex 0532610671. Mating part: Molex 0510210600. Signal Not connected ground Video input 1 ground Video input 2 ground Audio inputs – JP2 Molex 0532610771. Mating part: Molex 0510210700. Signal Ground Mic input + Mic input - Ground Line in, right Ground...
  • Page 8: Power - Jp3

    +Vin (9-36V DC) * Configuration mode contact. Connect to Ground to enter Configuration mode (see Network Configuration chapter). ** GPIO functionality is not implemented in the firmware. Please contact Sensoray with specific requirements. MicroSD card extension, JP5 Molex 0532610871. Mating part: Molex 0510210800.
  • Page 9: Ethernet - Jp7

    Ground Ground USB DM USB DP USB Vbus (output) Note: No specific RS232 and I2C functionality is implemented. Please contact Sensoray to discuss the requirements. Ethernet – JP7 Molex 0532611271. Mating part: Molex 0510211200. Signal 4, 5 Not used 7, 8...
  • Page 10: Specifications

    Specifications Video Input Standards HD-TVI, HD-CVI, AHD Maximum 1920x1080p30 resolution/frame rate Output video streams H.264 High Profile @ Level 3 (MP4, AVI, transport stream) JPEG Single snapshots, AVI Audio inputs Stereo line 10 kOhm Microphone electret type Electrical, mechanical and environmental Dimensions 26x53 mm Mass...
  • Page 11: Firmware Updates

    The firmware update is initiated using web interface. That requires a computer, located on the same network as the 2431. Using any browser connect to the 2431, and select Admin/Update, which will bring up the window that displays the versions of the device's firmware components and the serial number.
  • Page 12: Network Configuration

    LAN using an Ethernet patch cable, Cat5 or better. The 2431 automatically detects the type of the host interface, so it can be connected both to the computer and to a switch (hub) using the same type of cable.
  • Page 13 Now switch the 2431 into the Configuration Mode by pressing the configuration button. Note: you need to wait 15 seconds after the 2431 is powered up before the board is able to switch to Configuration Mode. Once the 2431 receives a network packet addressed to it, the temporary IP address will be in effect.
  • Page 14: Revision History

    Revision history Version Notes 1.0.0, March 2020 Initial release.
