Project Serve Assembly Guide
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Project Serve Features . . . . . . . . . . . . . . . . . . . . . . . . . 3
Package Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Site Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking Project Serve . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Project Serve . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing The Front Panel Bezel . . . . . . . . . . . . . . . . . . . 7
Connecting The Appliance to The Power . . . . . . . . . . . . . 9
Powering On The Appliance . . . . . . . . . . . . . . . . . . . . . . 9
Connecting Project Serve to the Network . . . . . . . . . . . . . 9
Hardware Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Monitoring the System Status . . . . . . . . . . . . . . . . . . . . 13
Monitoring Power Supply . . . . . . . . . . . . . . . . . . . . . . . . 14
Post Installation Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 14
Replacing a Failed Power Module . . . . . . . . . . . . . . . . . . 14
