Thank you for your purchase of this unique product for your Ford
Mustang! With these modules, you will be able to control the color
of your factory-installed DRL LED "bars" inside the headlight. They
are a direct replacement for the factory LED panels that illuminate
the bars.
Please note: Headlights must be opened before proceeding with installation. Professional installation
is strongly recommended. Please contact Diode Dynamics if you need assistance locating an installer.
Tools needed: Screwdriver
PAGE 1
2013-2014 Ford mustang
RGBw
LEd Board installation Guide
Tm
1. Remove the factory LED panels by unscrewing the
screws holding the reflector housing in place and
then unclip the wire connector.
2. Next, remove the two screws holding the LED panel
to the reflector housing and remove the factory LED
panel. The factory panel and driver board will no
longer be used.
3. Place the new Diode Dynamics LED Module into
position. Use the original screws to secure in place.
DO NOT OVERTIGHTEN.
(314) 205-3033
3 yEAR
WARRANTY
See back for further instructions.
