1
CHARGING PROCEDURE
Connect the battery charger to the power supply and the
indicator light should turn to green.
Slide the charger base on the battery pack to make
connections and the indicator light will turn red to show
that the charging has started.
When charging is completed, the light will turn to green.
2
INSTALLING THE BATTERY PACK
After recharging, insert the battery pack into the
battery port. A simple push and
slight pressure will be sufficient until a click is heard.
Check to see if the battery is fully secured.
20
HT19-401-003-11
VOLT
Cordless Chain Saw
3
ASSEMBLY INSTRUCTIONS
Grip the chain tensioning outer rim and turning it
anti-clockwise to loosen the chain.
Hold and depress the cover tightening stick, turning it
anti-clockwise to remove the chain cover.
MAX
