Lumex 69603A Assembly & Operation Instructions

Tools required: an adjustable wrench
Info: The most current version of these instructions can be found online at
WARNING: Important! Read and understand these instructions before
assembling or using the 69603A Bathtub Safety Rail. If you do not
understand any part of these warnings, cautions or instructions,
contact a healthcare professional for direction in the use of this
product. If the 69603A Bathtub Safety Rail is not properly assembled
and adjusted, personal injury and damage to the Bathtub Safety Rail
could result.
WARNING: If components are damaged or missing, contact your dealer
immediately. DO NOT use substitute parts. Use only Lumex replacement
parts. Non-Lumex replacement parts could cause personal injury and
damage to the Bathtub Safety Rail.
WARNING: This product has a weight limit of 300 lb, EVENLY DISTRIBUTED.
WARNING: Notice for California Customers- California Proposition 65
WARNING: This product contains a chemical known to the State of
California to cause cancer and reproductive or developmental harm.
WARNING: This product is NOT recommended for use on fiberglass or
plastic bathtubs. GF Health Products, Inc. assumes no responsibility for
any damage or injury caused by improper assembly or use of this product.

INSTALLATION

1. Remove the Bathtub Safety Rail from the box and place it on a flat, dry
surface.
2. Remove the four suction cups from the box.
3. Take one suction cup, insert its threaded rod into the Bathtub Safety
Rail leg's threaded hole, and turn the suction cup clockwise until tight.
4. Repeat step 3 for the remaining three suction cups.
5. Locate section of bathtub wall where Bathtub Safety Rail is to be
mounted. The Bathtub Safety Rail should be mounted ONLY on the
straight — not curved — part of bathtub wall. Ensure the tub surface
where the suction cups will be installed is smooth, clean, and dry
before installing the Bathtub Safety Rail. Clean and dry the suction
cups to remove any dust, powder, or foreign particles.
6. Use the wrench to loosen the adjustment nuts. Start with the bottom
nut and loosen it approximately four turns, then loosen the top nut
approximately four turns. Continue loosening the adjustment nuts
as described until the Bathtub Safety Rail is wide enough to fit your
bathtub.
7. Place the Bathtub Safety Rail in the desired location on the bathtub. Position it with the adjustment
nuts on the outside of the bathtub, as shown at right.
8. Use the wrench to tighten the adjustment nuts. Start with the bottom nut and tighten it
approximately four turns, then tighten the top nut approximately four turns. Continue tightening
the adjustment nuts as described until the Bathtub Safety Rail is securely fastened to the bathtub.
69603A-INS-LAB-RevC14
69603A: BATHTUB SAFETY RAIL
ASSEMBLY & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
www.grahamfield.com.
69603A Bathtub
Safety Rail
adjustment
nuts
outside
of tub
suction cups
Tub Section
1
