Cobra microTALK MT 925 PRO Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

ENGLISH
Antenna
Power/Transmit-Receive Indicator
TALK Button
LIGHT/MAX
RANGE Button
CALL Button
LOCK Button
Speaker/Microphone
Roger Beep Icon
VibrAlert
®
/Call Alert
Channel Number
DCS Code
VOX
CTCSS Privacy
Code
This equiment is intended for use in:
AT
•
EE
•
HU •
BE
•
ES
•
IE
•
CY
•
FI
•
IS
•
CZ
•
FR
•
IT
•
DE
•
GB •
LT
•
DK
•
GR
•
LV
•
• Countries of use
Two-Way Radio Model MT 925 PRO
External Speaker/
Microphone Jack
CTCSS Privacy
Code or DCS
Code Numbers
Keystroke Tone
Power Saver
Battery Level
LI
•
PT
•
LU
•
SE
•
MT •
CH •
NL
•
SI
•
NO •
SK
•
PL
•
TR
•
Battery Charge Contacts
Battery Compartment
Wrist Strap Connection Location
Lock
Receive/Transmit
Memory Location Number
Memory
Scan
Dual Watch
Belt Clip
Lock Tab
ON-OFF/VOLUME
Knob
CHANNEL UP/
CHANNEL DOWN Buttons
Intercom Jack
ENTER Button
MODE Button

Advertisement

Table of Contents
loading

Related Manuals for Cobra microTALK MT 925 PRO

Summary of Contents for Cobra microTALK MT 925 PRO

  • Page 1 Two-Way Radio Model MT 925 PRO ENGLISH Antenna External Speaker/ ON-OFF/VOLUME Microphone Jack Knob Power/Transmit-Receive Indicator CHANNEL UP/ TALK Button CHANNEL DOWN Buttons LIGHT/MAX Intercom Jack RANGE Button ENTER Button CALL Button MODE Button LOCK Button Speaker/Microphone CTCSS Privacy Code or DCS Code Numbers Keystroke Tone Lock...

  • Page 2: Product Features

    PRODUCT FEATURES OPERATION English Product Features • Two-Way Radio • Auto Squelch with up to a 3 km (2 mile) range • Selectable On/Off "Roger Beep" • 8 Channels * Confirmation Tone • 38 CTCSS Privacy Codes • Selectable On/Off Keystroke Tones •...

  • Page 3: Radio Power

    OPERATION English Battery Pack and Desktop Charger Battery Pack & Desktop Charger Your microTALK ® radio includes a rechargeable NiMH battery pack (part No. FA-BP) and a rapid desktop charger (part No. PA-CX). Your rapid desktop charger is capable of recharging one (1) radio (with battery pack installed in battery compartment) or one (1) battery pack using the included battery pack guide in the radio charging well.

  • Page 4: Battery/Power Saver

    OPERATION English Battery/Power Saver Power Saver Icon If there are no transmissions within ten (10) seconds, the unit will automatically switch to Battery Save Mode and POWER SAVER will appear on the display. This will not affect the unit’s ability to receive incoming transmissions.

  • Page 5: Display Illumination

    OPERATION English Lock Feature Lock Icon The LOCK button locks the CHANNEL UP, CHANNEL DOWN, MODE and ENTER buttons to prevent accidental operation. To Use the Lock Feature: 1. Press and hold the LOCK button for two (2) seconds to turn the Lock Lock Button Feature On or Off.

  • Page 6: Dcs Codes

    MODE FUNCTIONS English Scrolling Through the Mode Functions By scrolling through the Mode Functions, you will be able to select or change preferred features of your microTALK ® radio. While you are scrolling through the Mode Functions, your radio features will be displayed in the same predetermined order: Set CTCSS Privacy Codes Set DCS Codes Set VOX On/Off...
  • Page 7 MODE FUNCTIONS English To Select a DCS Code: Select Channel 1. After selecting a channel, press and release the MODE button until the DCS icon and current setting (the small numbers next to the channel number or Off) flash on the display. 2.

  • Page 8: Memory Locations

    MODE FUNCTIONS English 10 Memory Locations Memory Icon Your microTALK ® radio has ten (10) memory locations (0 to 9) for storing your most frequently used channel/privacy codes or channel/DCS codes. While in Memory Location options, you can program and/or recall memory locations. These memory locations can also be scanned (see “Scan Memory Locations”).

  • Page 9: Channel Scan

    MODE FUNCTIONS English To Recall a Stored Memory Channel Mode Button Select Memory Location Location: 1. Press the MODE button until the Memory icon and the memory location number (0 to 9) flash on the display. 2. Press the CHANNEL UP or CHANNEL DOWN button to select a Channel Buttons memory location number (0 to 9).
  • Page 10 MODE FUNCTIONS English b. Press the MODE button to proceed to set CTCSS privacy code or DCS code scanning on the channel that was either displayed before you entered Mode Functions or on which, during scanning, you last received a transmission. (see “CTCSS Privacy Code Scan”...
  • Page 11 MODE FUNCTIONS English DCS Code Scan Scan Icon Your microTALK ® radio can automatically scan the DCS codes (01 to 83) within one (1) channel. NOTE: If your radio is set to CTCSS Privacy Code mode, the DCS Code Scan option will not be available. See “DCS Codes” to turn DCS Code mode On.
  • Page 12 MODE FUNCTIONS English To Scan Memory Locations: Mode Button 1. Press the MODE button until the Scan icon, the Memory icon and the memory location number flash on the display. 2. Press the CHANNEL UP or CHANNEL DOWN button to begin scanning memory locations.

  • Page 13: Dual Watch

    MODE FUNCTIONS English Dual Watch Dual Watch Icon Dual watch allows you to simultaneously monitor any two (2) Dual Watch Locations. Dual Watch Location 1 – is always the channel/privacy code or channel/DCS code displayed before you entered Mode Functions. See “CTCSS Privacy Codes” and “DCS Codes” sections for further details.
  • Page 14 MODE FUNCTIONS English During An Incoming Transmission, You Can Choose From The Following: a. Press and hold the TALK button to communicate on that Dual Watch Location. Your radio will remain on that Dual Watch Location and return to LISTENING MODE. b.

  • Page 15: "Roger Beep" Confirmation Tone

    MODE FUNCTIONS English "Roger Beep" Confirmation Tone Roger Beep Icon Your listener will hear an audible tone when you release the TALK button. This alerts the other party that you have finished talking and that it is OK for them to speak. This feature can be turned On or Off. To Turn “Roger Beep”...

  • Page 16: Declaration Of Conformity

    MA-VOX MA-EBM 1177 For use in EU countries, subject to local laws and regulations. CEEL™ is a trademark of Cobra Electronics Corporation, USA. Snake design and microTALK are registered trademarks of Cobra Electronics Corporation, USA. ® ©2003 Cobra Electronics Europe Limited ®...
