About Manuals This TV comes with the following manuals. Please retain the manuals for future reference. Setup Guide • TV installation and setup. Reference Guide (this manual) / Safety Documentation • Safety information, remote control, troubleshooting, wall-mount installation, specification, etc. Help Guide (On screen Manual) •...
Page 3
• When transporting the TV set, do not subject it to jolts or excessive vibration. Remote Control and TV • When transporting the TV set for repairs or when moving, pack it using the original carton and packing material. Topple prevention The remote control shape, location, (Models with supplied support belt kit) availability and function of remote control...
GUIDE/ Display the digital programme guide. Installing the TV to the Wall APPS: Display a list of installed apps. (Input select): Using the optional Wall-Mount Bracket Display and select the input source, etc. (SU-WL450)* (not supplied) (Quick settings): Display Quick Settings.
Page 5
Detaching the Table-Top Stand from the TV • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. The supplied screws are designed as indicated by illustration when measured from the attaching surface of the Wall-Mount Bracket.
Troubleshooting Specifications General troubleshooting for issues like: black System screen, no sound, frozen picture, TV does not Panel system: LCD (Liquid Crystal Display) Panel, respond, or network is lost, do the following LED Backlight steps. TV system Restart your TV by pressing the power button Analogue: I, D/K, B/G, M on the remote control for about five seconds.
DIGITAL AUDIO OUT (OPTICAL) Operating temperature: 0 ºC - 40 ºC Digital optical jack (Two channel linear PCM: Operating humidity: 10% - 80% RH 48 kHz 16 bits, Dolby Audio, DTS) (non-condensing) (Stereo mini jack) *1 When 4096 × 2160p is input and [Wide mode] is set Headphone to [Normal], the resolution is displayed as 3840 ×...
Page 8
關於說明書 本電視機附帶以下說明書。請保管好這些說明書,以供日後參考。 安裝指南 • 電視機安裝和設定。 參考指南 (本說明書)/ 安全檔案 • 安全資訊、遙控器、故障排除、壁掛式安裝、規格等。 說明指南 (電子說明書) • 您可以使用您的智能手機來查閱說明指南。 • 設定、Android TV 功能、網際網路 連線、故障排除等。 https://rd1.sony.net/help/ • 想要打開說明指南,請按遙控器上的 tv/hga1/h_ga/ 按鈕,選擇說明指南。 HELP • 安裝電視機,使電視機的桌面底座不會從電視機櫃 (非附帶) 重要 – 在使用 Sony 產品之前,請先閱讀終端使用者軟體授權 凸出。如果桌面底座從電視機櫃凸出,可能導致電視機翻倒、掉落 合約。若使用您的產品,則表示您接受終端使用者軟體授權 及人身傷害或對電視機造成損壞。 合約。您與 Sony 之間的軟體授權合約可在 Sony 網站 (http:// www.sony.net/tv-software-licenses/)上線上獲取,也可在您...
