DVLD-1
Lightning Detector
User Manual
Version 1.0
August 2015
MAN1027
Davicom, a division of Comlab Inc.
2300, Leon-Harmel, suite 220, Quebec, QC, Canada
G1N 4L2
Tel: +1.418.682.3380 Fax: +1.418.682.8996

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVLD-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Davicom DVLD-1

  • Page 1 DVLD-1 Version 1.0 Lightning Detector August 2015 MAN1027 User Manual Davicom, a division of Comlab Inc. 2300, Leon-Harmel, suite 220, Quebec, QC, Canada G1N 4L2 Tel: +1.418.682.3380 Fax: +1.418.682.8996...
  • Page 3 Davicom Lightning Detector User Manual www.davicom.com DVLD User Manual...

  • Page 4: Table Of Contents

    Table of Contents General Information ......................3 Limited Warranty ......................3 Safety .......................... 3 Regulatory Compliance ...................... 4 Background ........................5 Installation and initial configuration ..................5 Extra information on operation of the DVLD ............... 8 Averaging time & distance thresholds ................8 Timeout delays ........................

  • Page 5: General Information

    1.2 Safety The Davicom DVLD should be installed by qualified technical personnel only. Installation of this device by an unqualified person could result in hazardous conditions to the installer or other personnel, and/or damage the DVLD or other equipment.

  • Page 6: Regulatory Compliance

    2 Regulatory Compliance FCC (USA) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 7: Background

    Together, the DVLD and Davicom units can be used to detect approaching lightning storms, to send alarms when the storm reaches a certain minimum distance, to de-activate or disconnect sensitive equipment and even to log the storm’s track.
  • Page 8 8) In the DavLink software, go to the configuration menu by clicking on the configuration icon or select Unit from the main menu and Unit Configuration from the dropdown list. 9) Click on Devices. Next, click on the Davicom Expansions tab and finally click on the DVLD tab.
  • Page 9 a Minor alarm should the DVLD stop communicating. This is illustrated in the following screen shot. 17) A display button is then created through the DavLink display edition window as shown on the left below. It will appear as on the right below. 18) The second flag/variable from the DVLD is the 1LD01 flag.

  • Page 10: Extra Information On Operation Of The Dvld

    5 Extra information on operation of the DVLD 5.1 Averaging time & distance thresholds Independently of the Davicom’s settings, the DVLD’s internal circuit is always operating and actively listening for the electromagnetic signature of lightning strikes. It can detect both cloud- to-ground and cloud-to-cloud strikes.

  • Page 11: Timeout Delays

    40 km, it will output this number to the Davicom unit for further action. Actually, the Davicom unit reads the data out of the DVLD once every second. It is important to note that this averaging and distance estimation takes place on a 17 minute cycle in the hardware.

  • Page 12: Hands-Off Setup

    For DV-Mini or DV-2-8/216 units, the control could also take the form of sending an SNMP trap or performing an SNMP SET. If you wish, the Davicom can also be configured to send an alarm when the Distance Trigger event occurs, in addition to the local control commands. The example below shows an e-mail address configured as an alarm destination.

  • Page 13: Hands On Setup

    To achieve this dual-threshold capability, it is necessary to use the Metering Math Functions built-in to the Davicom units. The MMF’s have two-level alarm capability built-in. The example below shows that a Minor Alarm has been set for a minimum distance of 30 km and a Major Alarm has been set for a minimum of 10 km.
  • Page 14 This Metering Math Function feature only works with firmware 5.56.17355 or more recent. DVLD User Manual...

  • Page 15: Logging

    7.3 Logging The DVLD and Davicom units can also be used to log lightning storm activity in the vicinity of your site. The data can be transferred at periodic intervals and compiled in Excel to produce a chart of storm activity and proximity to the site. The figure below shows the DVLD range data of a real thunderstorm that passed right over our offices in the evening on June 18 2015.
  • Page 16 Firstly, the « Custom Log » box must be checked as shown below. Then, the Custom Log can be configured as shown below to transfer the log by e-mail when it reaches 90% capacity. The Data logging must be activated to take periodic samples (every 5 minutes in this example).

  • Page 17: Support/Contact

    8 Support/Contact For more detailed information on setting up and using the advanced features of your Davicom unit, please refer to the Davicom Reference Manual For technical support concerning this product, please consult the www.davicom.com web site or contact us: •...
