Rolls BT287 Connection Manual

DESCRIPTION:

The Rolls BT287 is a Bluetooth interface that
will supply stereo or mono audio to a sound
system. It also features a 400 watt contact
closure relay for activation of the connected
system. For example, if you have a sound
system such as an old juke box and want to
add Bluetooth capability to it. The BT287 will
supply audio to the juke box as well as pro-
vide a contact closure relay to turn the juke
box on, controlling cabinet lights, amplifier and
audio level remotely. When audio is sent to the
BT287 the juke box will turn on automatically
and start playing audio, when Bluetooth audio
is not present the juke box will be powered off
by the BT287. This way a homeowner or shop
owner could have a piece of equipment (juke
box) remotely controlled via laptop, phone,
tablet or other digital Bluetooth device with the
BT287.

What's in the box?

1 - Made in USA BT287
1 - 15V power supply PN PS27s
1 - This owners manual
Rolls Corporation
Salt Lake City, UT
1/20
Made in USA ww.rolls.com

OPERATION:

To pair a device to the BT287 simply find
the BT287 (ROLLSBT) on your device
and connect. After the device is connected
to the BT287 a steady blue led will light
indicating that the BT287 is paired to a
device, but no audio is present. A slow
blinking blue light indicates that audio is
being sent when paired.
When powered off the BT287 will remem-
ber the device it was previously paired
with. On power up will search for that
device and reconnect to it.
The DB287 has a Bluetooth operating
range of 15 to 40 feet depending on how
and where it is installed.
Made in USA ww.rolls.com
BT287 Bluetooth
Audio Adapter with switch

SPECIFICATIONS:

Output Impedance:
Power Requirements:
Size:
Weight:
Connection guide
1K Ohm RCA
15 VDC, 500 mA;
Rolls part number PS27s
3.75" x 3.25" x 1.5"
1 lb.
