Rolls BD87 Connection Manual

DESCRIPTION:

The Rolls BD87 is a bluetooth audio
adapter. It will convert any devices blue-
tooth signal to analog. Designed for any
system, home, professional or installa-
tion.

CONNECTION:

The BD87 outputs are XLR Mic level bal-
anced mono, RCA stereo or 1/8" stereo
line level outputs.
The level control will adjust all outputs.
When the blue indicator light is blinking
fast the BD87 is not paired with any unit.

What's in the box?

1 - Made in USA BD87
1 - 15V power supply PN PS27s
1 - This owners manual
Rolls Corporation
Salt Lake City, UT
5-19
Made in USA ww.rolls.com
To pair a device to the BD87 simply find
the BD87 (ROLLSBT) on your device and
connect. After the device is connected to
the BD87 a steady blue led will light indi-
cating that the BD87 is paired to a device,
but no audio is present. A slow blinking
blue light indicates that audio is being sent
when paired.
The reset button can be used to stop a
device from being paired so a different de-
vice can be paired. The previously paired
device must be off, its Bluetooth discon-
nected from the BD87, our out of range
as the BD87 remembers the device it was
previously connected to and will continu-
ally search for that device until a different
device is paired.
When powered off the BD87 will remem-
ber the device it was previously paired
with. On power up will search for that
device and reconnect to it.
BD87 Bluetooth Audio Adapter
Made in USA ww.rolls.com

SPECIFICATIONS:

Output Impedance:
Power Requirements:
Size:
Weight:
• Professional bluetooth audio adapter
• Stereo RCA and 1/8" Outputs

• Mono XLR mic level output

• Powder coated steel chassis
Connection guide
1K Ohm RCA, 1/8"
600 Ohm XLR
15 VDC, 500 mA;
Rolls part number PS27s
3.25" x 3" x 1.5"
1 lb.
