ANXELL E-Access E3AK Series Instructions Manual

E3AK1
4-3/4" x 2-15/16" x 1-13/16"
(120 x 74 x 46.2 mm )
Features
1 Administrator, 1000 users
2 Access Modes: Use Bluetooth
smartphone or enter 4 to 8 digit
Passcode to access
Built-in tamper alarm and buzzer 85dB
User Management: Add/delete/view user
data, grant user access for specific dates
or time periods, change user passcode,
or enable/disable user keypad entry
Audit Trail logs for last 1000 events
The keypad will be disabled for one
minute when 3 failed passcode attempts.
T +886-2-2205-2228
®
F +886-2-2205-2225
E E
-Access
E3AK Access Control Keypads
®
Instructions
E3AK2 2 E3AK2
4-1/2" x 2-3/4" x 1-5/8" 4-1/2" x 2-3/4" x 1-5/8"
(114 x 70 x 41 mm)
E info@anxell.com
W www.anxell.com
®
E3AK3
4-13/16" x 3" x 2-1/2"
(123 x 77 x 64.2 mm)
Specifications
Voltage (Input): 12 to 24 VDC
Current Draw:
Standby current: 16mA@12VDC, 7mA@24VDC
Working current: 18mA@12VDC, 9mA@24VDC
Bluetooth module: BLE 4.2
Operating distance : Up to 50 meters(164 ft)
Smartphone Compatibility: Android 5.0 to 8.0,
Finishes/Colors: Dark Brown or Navy
ANXELL TECHNOLOGY CORPORATION
No.304, Xinshu Rd., Xinzhuang Dist.,New Taipei City 242, Taiwan (R.O.C.)
E3AK4 E E3AK4
3-7/16" x 3-7/16" x 1-3/4"
(87.3 x 87.3 x 45.2 mm)
without blocking by metal or
concrete wall/door frame.
iOS 9.0 and up
2018/04/16 ver. 1.2
1
