Summary of Contents for Hoover 7000PH Allergy
- Page 1 Bagged Vacuum Cleaner with Deep Cleaning Powerhead High Efficiency Motor Carbon & HEPA Filtration Self-Propelling Powerhead...
-
Page 3: Specifications
7000PH Allergy Congratulations on the purchase of your new HOOVER vacuum cleaner. There are many useful features built into your vacuum cleaner. We recommend that you carefully read this instruction manual for the best results. Features: Handle On/Off Button 2. On/Off Button (Powerhead) 10. -
Page 4: Before You Begin
Before you Begin This cleaner must be operated in accordance with these instructions and used only for domestic household cleaning to remove DRY dirt and dust from household carpets, flooring, walls and fabrics. This cleaner is not fit to be used as an industrial cleaner and will void the manufacturer’s warranty if used inappropriately. -
Page 5: Safety Precautions And Warnings
Safety Precautions & Warnings IMPORTANT! Always switch off the cleaner and remove the power plug from the electricity power supply before cleaning your appliance, when not in use or attempting any maintenance task. The cleaner must only be connected to an AC power supply at the voltage shown on the rating label. - Page 6 17. To prevent electrical shock, do not use the 27. Never attempt to make any modifications to the vacuum cleaner outdoors or on wet surfaces. vacuum cleaner. 18. Extreme caution should be exercised when 28. Always store the appliance indoors, in a cool, using the appliance on stairs.
-
Page 7: Flexible Hose
Assembly IMPORTANT! Always remove the power plug from the power supply before fitting or removing accessories! 1. Flexible Hose Fitting: Insert the flexible hose into the hose inlet of the vacuum. Press until it clicks into position. Removing: Press the two buttons and gently pull to release the flexible hose. 2. -
Page 8: Crevice Tool
Accessories (continued) Powerhead Powerhead Height Adjustment Button Deeply cleans carpets by effectively lifting and removing deeply embedded dust and dirt. The height of the powerhead can be adjusted to be used on different types of carpet. Note: not recommended for use on hard floors. WARNING! Do not use the powerhead on woolen or delicate carpets. -
Page 9: Upholstery Tool
Accessories Upholstery Tool For vacuuming furniture and upholstery. Mini Hand Turbo Brush The Mini Hand Turbo Brush is ideal for picking up pet hair from furniture & upholstery. This accessory features a transparent case so that you can easily see and remove any blockages that may occur. Safety Precautions: 1. -
Page 10: Blockage Indicator
Instructions for Use Using the Suction Control Dial The suction power can be regulated by using the Suction Control Dial to achieve optimum cleaning results. To change the suction power to suit a particular cleaning task, simply turn the dial to point at the appropriate symbol. -
Page 11: Using The Handle
IMPORTANT! Always remove the power plug from the power supply before fitting or removing accessories. Turning On/Off the Cleaner 1. Unwind a sufficient length of cable. The yellow mark on the power cable shows the ideal cable length. DO NOT extend the cable beyond the red mark. 2. -
Page 12: Maintenance
Maintenance IMPORTANT! Always remove the power plug from the power socket before performing any maintenance. Vacuum Cleaner Storage When not in use, ensure that the cleaner is disconnected from the power supply and that the cable is fully retracted. The combination floor tool can be stored in the floor park clip. The powerhead must be stored separately. - Page 13 Remove the dust bag when it is full and replace with a new dust bag. Reinsert the bracket and dust bag assembly. Gently close the Dust Bag Cover, ensuring it clicks into place. Cleaning and Replacing the Pre-Motor Filter IMPORTANT! Always remove the power plug from the power socket before performing any maintenance.
- Page 14 Maintenance (continued) Cleaning and Replacing the Rear Motor HEPA and Carbon Filter The Rear Motor HEPA and Carbon Filter is installed behind the exhaust grille. This filter is washable, however frequent washing of the carbon filter can reduce the life of the carbon filter. When dust or dirt is visible on the surface of the HEPA filter, the filter should be replaced or washed with lukewarm water to maintain efficient suction.
- Page 15 The rotating bristles must be unlocked and in the upward position. To unlock the rotating bristles push the lock button on the side of the turbo brush to the downward position. Remove the clear cover. Remove any dirt or hair from the roller brush. Replace the clear cover.
- Page 16 Maintenance (continued) Cleaning the Agitator Bar WARNING! Ensure that the cleaner is disconnected from the power supply and the powerhead is disconnected from the rod before performing any maintenance. Note: The agitator bar must be free of debris for effective cleaning and for maximum suction.
- Page 17 Replacing the Powerhead Drive Belt & Agitator Bar WARNING: To reduce the risk of electric shock, ensure that the power is switched off and the power plug is disconnected from the power supply before performing any cleaning, maintenance or troubleshooting checks. Failure to do so may result in electric shock or personal injury.
-
Page 18: Spare Parts
Spare Parts Please contact Hoover Customer Care: 1300 360 845 (AUS) 0800 387 442 (NZ) to find your local spare parts provider. Description Product Code Filter Set (Pre-motor & Rear Motor Filters) 32200931 Dust Bag Bracket Assembly 33151857 Dust Bags (5 Pack) -
Page 19: Troubleshooting
Troubleshooting Problems and Solutions If you come across a problem, please use the checklist of troubleshooting tips before ringing Hoover Customer Care 1300 360 845 (AUS) 0800 387 442 (NZ). Fault Solutions The cleaner will not turn on. Check that the power cable is inserted securely; remove from the power supply and then reinsert into the power supply. -
Page 20: Conditions Of Warranty
Bagged Vacuum Cleaner with Deep Cleaning Powerhead Conditions of warranty Your Hoover cleaner, in the case of domestic use, has a two years Hoover Floorcare is unable to accept responsibility under this parts and labour warranty against product defects and failures when...
