- Page 1 Pallet-Pool Lifter Solenoid Valve Assembly - Replacement - EC-400PP - AD0149 LAST UPDATED: 12/01/2018 Lifter Solenoid Valve Assembly - Pallet-Pool - Replacement - EC-400PP AD0149 Applies to machines built from: July, 2005 to August, 2014 Page 1 of 6 pages...
- Page 2 Pallet-Pool Lifter Solenoid Valve Assembly - Replacement - EC-400PP - AD0149 Lifter Solenoid Valve Assembly - Pallet-Pool - Removal Page 2 of 6 pages...
- Page 3 Pallet-Pool Lifter Solenoid Valve Assembly - Replacement - EC-400PP - AD0149 Turn off the air. [POWER OFF] the machine. Lockout/tagout the main circuit breaker. Remove the (16) screws [1] from the cover on the slider casting. Remove the (4) cable carrier screws [1] and the cable carrier [2].
- Page 4 Pallet-Pool Lifter Solenoid Valve Assembly - Replacement - EC-400PP - AD0149 Remove the: • Pallet-pool lifter solenoid valve assembly socket-head cap screws (SHCS) [1]. • Pallet-pool lifter solenoid valve assembly washers [2]. • The pallet-pool lifter solenoid valve assembly [3]. Remove the (2) cylinder air tube fittings [1].
- Page 5 Pallet-Pool Lifter Solenoid Valve Assembly - Replacement - EC-400PP - AD0149 Lifter Solenoid Valve Assembly - Pallet-Pool - Installation Page 5 of 6 pages...
- Page 6 Pallet-Pool Lifter Solenoid Valve Assembly - Replacement - EC-400PP - AD0149 Install the muffler [1] on the top air cylinder port [2]. Install the replacement pallet-pool lifter solenoid valve assembly from the kit [1] to the bottom air cylinder port [2]. Connect the main air-tube [1] to the replacement pallet-pool lifter solenoid valve assembly [2].
