Basalte Aalto D4 Installation Manual

Aalto D4
Installation Manual
Before operating the unit, please read this manual thoroughly and retain it for future reference.
Model No. 0513-xx
You are cautioned that any changes or modifications not expressly approved in this manual could void your
authority to operate this equipment.

Description

Aalto D4 is an active speaker that can be placed on the wall or freestanding.
The speaker can connect an optical input and a Bluetooth audio device.
Aalto D4 can only be used in combination with S4.
The speakers are compatible with all D4 fabric covers (501-xx not included).
4

LED feedback

The front panel has a feedback LED which indicates following statuses:
• Blue: standby mode
• White: speaker is active
• Blinking red: clipping detection

Dimensions

Speaker: 160 x 995 mm (height x width)
Depth: 80 mm
5
2
3 1 4
6
1 Audio network
2 Optical input
3 Power supply (230V AC)
4 Wall bracket
5 Status LED
6 Speaker stand (0514-03 not included)
