Speaker Phone
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP200 and is the answer not in the manual?

Questions and answers

Related Manuals for Kaysuda SP200

Summary of Contents for Kaysuda SP200

  • Page 1 Speaker Phone User Manual...
  • Page 2 1. Package Contents 2. Product introduction SP200 is Smart Wireless Conference speakerphone. This product can connect with PC, tablet and smartphone via Bluetooth or USB. It supports omnidirectional microphone and high communication quality speaker to realize it can play and receive voice of 360 in long distance. It is small and portable, convenient fixed office and mobile office.
  • Page 3 Press power button and hold on 3s again, the device will power off and all LED will be off. 4. How to charge Please insert USB cable in the micro USB port of SP200. Then connect USB type A interface with PC’s USB port or 5V external charger.
  • Page 4 USB mode; • Please set the SP200 as default output and input audio device. 2. Connect with smartphone /host device with Bluetooth • Press power button and hold on 3s, the white power indicator LED will light up and the...

  • Page 5: Operation

    6. How to operate ICON FUNCTION OPERATION Power on/off Press and hold(3s) this button until the white power indicator LED is on Display battery level Tap this button Mute/unmute Tap this button Turn up the volume Tap “+” button Turn down the volume Tap “-”...

  • Page 6: Specification

    7. Product Specification Warning SPEAKERPHONE SP200 SPECIFICATION Only could be used in areas below 2000 meters above sea Microphones Omni-directional，4 MICs level; Only applicable to non-tropical Speaker 3W, Dynamic, 40mm climate conditions. Bluetooth range Up to 10m(30ft), Class2 Bluetooth version 4.2, compatible with...
  • Page 7 8. Trouble Shooting Problem or Phenomenon Possible Reasons Treatments Can’t power on Low battery Charge through adapter No sound Host system audio setting Selecting the correct output audio source; doesn’t select the right Turn up the speaker volume. output device; The speaker volume is very USB doesn’t work Doesn’t use the right USB...
