- Page 1 USER MANUAL TMT-HA100 Hot Air Pencil www.thermaltronics.com...
- Page 3 If the product should become defective within the warranty period, Thermaltronics will repair or replace it free of charge at its sole option. Warranty period is from the date of purchase by the original owner. If the date of purchase cannot be substantiated the date of manufacture will be used as the start of the warranty period.
- Page 4 Certification Marks: CE, ETL INTRODUCTION Congratulations on your purchase of the TMT-HA100 Hot Air Pencil. This unit has been tested and inspected by Thermaltronics prior to shipment, and with proper maintenance will give you years of reliable performance. SYSTEM FEATURES The TMT-HA100 hot air pencil is designed to remove and reflow small precision components, integrated circuits and other smaller devices.
- Page 5 9. When resting the handle in the handle holder, make sure there are no objects within 30cm of the nozzle, as nearby objects maybe damaged. 10. Do not apply excessive force when installing and removing nozzles. 11. Do not use pliers to pull the edges of the nozzle. www.thermaltronics.com support email: support@thermaltronics.com...
- Page 6 Important: Keep all shipping materials until satisfactory operation has been verified. Assembly 1. Remove TMT-HA100 Hot Air Pencil from its box and place on a suitable work bench. 2. Select the proper nozzle and secure it to the hot air pencil.
- Page 7 SPARE PARTS & NOZZLES PART# DESCRIPTION TMT-HA100-1 100-110V Hot Air Pencil TMT-HA100 220-240V Hot Air Pencil PART# DESCRIPTION A mm HAP-D15 Nozzle 1.5mm HAP-D20 Nozzle 2.0mm HAP-D25 Nozzle 2.5mm HAP-D30 Nozzle 3.0mm HAP-D35 Nozzle 3.5mm HAP-D40 Nozzle 4.0mm www.thermaltronics.com support email: support@thermaltronics.com...
- Page 8 Support Email: support@thermaltronics.com www.thermaltronics.com...
