- Page 1 heart rate assembly installation and use FOR INDOOR ROWER MODELS B, C, AND D concept2.com 800.245.5676 1207...
- Page 2 J-clip PN 1761 3 J-clips and Heart Rate (HR) receiver w/cable J-clip J-clip J-clip Thread wire into holders. J-clip J-clip HR receiver J-clip If signal is not picked up, place the receiver on the floor under the middle of the monorail.
- Page 3 installing heart rate interface on a model c J-clip PN 1761 3 J-clips and Heart Rate (HR) receiver w/cable 21”/53cm J-clip HR receiver J-clip J-clip For machines built after 7-1-95 J-clip For machines J-clip built before 7-1-95. Route wire through the framelock.
- Page 4 installing heart rate interface on a model d PN 1761 3 J-clips and Heart Rate (HR) receiver w/cable cable plug in 6. Monitor Arm Routing Detail 21”/53 cm J-clip J-clip J-clip HR receiver 3. Cable Routing for Model D Indoor Rowers purchased AFTER August 1, 2006.
-
Page 5: Troubleshooting
how to wear polar™ (or polar compatible) heart rate monitor 1. WET THE ELECTRODE AREAS OF ELASTIC CHEST BELT Wet the electrode area (the two rectangular areas on the underside of the chest belt transmitter) thoroughly under running water. 2. ATTACH THE CONNECTOR TO THE ELASTIC CHEST BELT Position the letter L on the connector next to the word LEFT on the chest belt and snap the fastener. - Page 6 monitoring heart rate to determine training intensity Medical authorities use the term “target zone” to describe the amount of physical activity which is enough to achieve fitness but not too much to exceed safe limits. This target zone is the level of activity which produces a heart rate of from 70-85% of the maximum attainable heart rate during all-out effort.
