Important Battery Tips
1. Charging the battery
Charge the battery until the battery indicator turns green only when it is completely dis-
charged
The battery deteriorates each time it is charged. By charging the battery only when it has become completely
discharged, you will reduce the number of charges, and thus extend the life of your battery. Do not charge the
battery repeatedly before it is discharged.
To help reduce the number of charges, the battery can only be recharged when the remaining power is less than
about 95% of capacity.
Charge the battery in a temperature range of 10°C to 30°C {50°F to 86°F}
The battery deteriorates more quickly when it is charged at high temperatures. Do not charge the battery in high
temperature environments, such as in a closed car in the hot sun.
When the battery temperature is outside the allowable temperature range, the battery indicator blinks orange and
charging will not begin.
Charge the battery while the computer is powered off
Even if the environmental temperature is within the allowable temperature range, if the computer's power is on,
the battery temperature rises due to the effects of heat from the CPU and other components. Since this heat can
lead to deterioration of the battery, we recommend that you only charge the battery when the computer is pow-
ered off.
Use the high temperature mode (only for models with high temperature mode*)
The high temperature mode is a function that prevents deterioration of the battery in high temperature environ-
ments.
We recommend setting the high temperature mode function when installing the computer in a car or other location
where the temperature may rise above the allowable temperature range. To do this, set [Environment] in [Main]
menu of the Setup Utility to [High Temperature].
We also recommend setting the high temperature mode function in the following situations.
When using the computer for a long period of time with the AC adaptor connected.
When long-term battery operation is not required.
* Models for which [Environment] is displayed in [Main] menu of the Setup Utility.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF-18B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Panasonic CF-18B

  • Page 1 ENGLISH Important Battery Tips 1. Charging the battery Charge the battery until the battery indicator turns green only when it is completely dis- charged The battery deteriorates each time it is charged. By charging the battery only when it has become completely discharged, you will reduce the number of charges, and thus extend the life of your battery.
  • Page 2 ENGLISH Important Battery Tips 2. Storing the battery pack If the battery pack will not be used for a long period of time (a month or more), to main- tain the performance of the battery, charge or discharge (use) the battery pack until the remaining battery level is between 30% and 40%, then remove it from the computer and store it in a cool, dry place.
  • Page 3: Using The Battery Pack Efficiently

    ENGLISH Important Battery Tips 3. Using the battery pack efficiently Leave the computer off when it is not in use Adjust the brightness (darker) of the LCD by pressing Fn + F1 Pressing the Fn + F1 keys will lower the degree of brightness, thereby reducing the power consumption. Before stepping away from your computer, press Fn + F7 (standby) or Fn + F10 (hibernation) to put your computer in the standby or hibernation mode Pressing these key combinations will put your computer in the standby or hibernation mode, thereby lowering the...
  • Page 4 ENGLISH Important Battery Tips 4. Things to keep in mind when using the battery pack Use or store the battery pack in the temperature range of 10°C to 30°C {50°F to 86°F} Do not leave the battery pack for extended periods where it will be exposed to direct sunlight, in a hot place (in a closed car in the hot sun, for example), or in a cold place.
  • Page 5: Refresh Battery

    ENGLISH Important Battery Tips 5. Refresh Battery The battery pack has a function for measuring, storing, and learning about battery capacity. Using this function properly to accurately display remaining battery capacity requires that the battery be fully charged (charged to 100%), then fully discharged, and then fully charged again.
  • Page 6: Laden Des Akkus

    DEUTSCH Wichtige Hinweise zum Akku 1. Laden des Akkus Wenn der Akku vollständig entladen ist, laden Sie ihn, bis die Akku-Anzeigelampe grün leuchtet Der Akku verliert mit jedem Ladevorgang an Leistung. Indem Sie den Akku erst laden, wenn er vollständig entladen ist, verringern Sie die Anzahl der Ladevorgänge und verlängern dadurch die Lebensdauer des Akkus.
  • Page 7: Lagern Des Akkus

    DEUTSCH Wichtige Hinweise zum Akku 2. Lagern des Akkus Um die Leistung des Akkus bei längerer Nutzungspause (1 Monat oder länger) aufrechtzuerhalten, laden oder entladen (benutzen) Sie den Akku, bis ein Ladezustand von 30% bis 40% erreicht ist; entfernen Sie den Akku dann aus dem Computer, und lagern Sie ihn an einem kühlen, trockenen Ort Wenn der Akku mit dem Gerät verbunden bleibt, wird er allmählich entladen, auch wenn der Computer ausgeschaltet ist.
  • Page 8 DEUTSCH Wichtige Hinweise zum Akku 3. Effiziente Verwendung des Akkus Schalten Sie den Computer aus, wenn er nicht benutzt wird Drücken Sie Fn + F1 , um die Helligkeit des LCD-Bildschirms zu verringern Mit der Tastenkombination Fn + F1 verringern Sie die Helligkeit und damit auch den Stromverbrauch. Bevor Sie sich vom Computer entfernen, drücken Sie Fn + F7 (Bereitschaft) oder Fn + F10 (Ruhezustand), um Ihren Computer in den Bereitschafts- bzw.
  • Page 9 DEUTSCH Wichtige Hinweise zum Akku 4. Beachten Sie Folgendes, wenn Sie den Akku verwenden Verwenden oder lagern Sie den Akku im Temperaturbereich von 10°C bis 30°C Setzen Sie den Akku nicht für längere Zeit direkter Sonneneinstrahlung, heißen Umgebungen (z. B. in einem Fahrzeug, das in der Sonne steht) oder kalten Umgebungen aus.
  • Page 10 DEUTSCH Wichtige Hinweise zum Akku 5. Auffrischen des Akkus Der Akku besitzt eine Funktion zum Messen, Speichern und Erfassen des Ladezustands. Um diese Funktion zum genauen Anzeigen des Ladezustands richtig zu verwenden, muss der Akku zuerst vollständig aufgeladen (auf 100%), dann vollständig entladen und anschließend erneut vollständig aufgeladen werden.
  • Page 11: Charge De La Batterie

    FRANÇAIS Conseils importants concernant la batterie 1. Charge de la batterie Chargez la batterie uniquement lorsqu’elle est complètement déchargée, jusqu’à ce que le voyant de charge tourne au vert La capacité de charge de la batterie diminue à chaque charge. En ne chargeant la batterie que lorsqu’elle est complètement déchargée, vous réduirez le nombre de charges et allongerez ainsi la durée de vie de la batterie.
  • Page 12 FRANÇAIS Conseils importants concernant la batterie 2. Conservation de la batterie Pour maintenir le niveau de performance du bloc-pile lorsqu’il doit demeurer inutilisé pour une période prolongée (un mois ou plus), chargez-le ou déchargez-le (en l’utilisant) jusqu’à ce que le niveau de la charge restante se trouve entre 30% et 40%, puis retirez-le de l’ordinateur et rangez-le dans un endroit frais et sec Lorsqu’elle reste connectée à...
  • Page 13 FRANÇAIS Conseils importants concernant la batterie 3. Utilisation efficace de la batterie Laissez l’ordinateur hors tension lorsque vous ne l’utilisez pas Ajustez la luminosité (plus foncé) de l’affichage à cristaux liquides en appuyant sur Fn + F1 Lorsque vous appuyez sur la combinaison de touches Fn + F1 , vous réduisez la luminosité, et donc la consommation d’énergie.
  • Page 14 FRANÇAIS Conseils importants concernant la batterie 4. Points importants à ne pas oublier pour la batterie Utilisez ou rangez le bloc-pile là où la température est dans une plage de 10°C à 30°C Veillez à ne pas laisser pour une période prolongée la batterie dans un endroit où elle sera exposée au rayonnement direct du soleil, à...
  • Page 15 FRANÇAIS Conseils importants concernant la batterie 5. Actualiser la batterie La batterie est dotée d’une fonction permettant de mesurer, de conserver et d’indiquer son niveau de charge. Pour que cette fonction opère correctement et affiche avec exactitude la charge restante de la batterie, il faut d’abord que la batterie ait été...
  • Page 16: Carica Della Batteria

    ITALIANO Suggerimenti importanti sulle batterie 1. Carica della batteria Caricare la batteria finché l’indicatore della batteria diventa verde soltanto quando è completamente scarica La batteria si deteriora ogni volta che viene caricata. Caricandola soltanto quando si è scaricata completamente, si riduce il numero di cariche e si prolunga così la sua vita. Non caricare ripetutamente la batteria quando non è completamente scarica.
  • Page 17: Conservazione Della Batteria

    ITALIANO Suggerimenti importanti sulle batterie 2. Conservazione della batteria Per mantenere le prestazioni della batteria se non si intende usarla per un lungo periodo di tempo (un mese o più), caricarla o scaricarla (usarla) finché ha una carica restante dal 30% al 40%, e rimuoverla poi dal computer conservandola in un posto fresco e asciutto Se la batteria viene lasciata collegata all’unità, si scarica gradualmente anche se il computer è...
  • Page 18 ITALIANO Suggerimenti importanti sulle batterie 3. Uso efficiente della batteria Lasciare il computer spento quando non lo si utilizza Regolare la luminosità (a un valore più basso) dell’LCD premendo Fn + F1 Premendo i tasti Fn + F1 si ridurrà il grado di luminosità, riducendo in tal modo il consumo di corrente. Prima di allontanarsi dal computer, premere Fn + F7 (standby) o Fn + F10 (ibernazione) per disporre il computer nella modalità...
  • Page 19 ITALIANO Suggerimenti importanti sulle batterie 4. Fattori da tenere in considerazione nell’utilizzo della batteria Usare o conservare la batteria in una gamma di temperatura compresa tra i 10°C e i 30°C Non lasciare la batteria per periodi di tempo prolungati esposta alla luce solare diretta, in ambienti molto caldi (per esempio, nell’automobile chiusa parcheggiata al sole,) o molto freddi.
  • Page 20 ITALIANO Suggerimenti importanti sulle batterie 5. Refresh della batteria La batteria dispone di una funzione per misurare, memorizzare e conoscere la capacità della batteria. Per poter usare correttamente questa funzione per visualizzare con esattezza la capacità restante della batteria, bisogna caricarla completamente (al 100%), scaricarla completamente e caricarla poi di nuovo completamente.
  • Page 21: Carga De La Batería

    ESPAÑOL Recomendaciones importantes sobre la batería 1. Carga de la batería Cargue la batería sólo cuando esté completamente descargada, y cárguela hasta que su indicador se encienda en color verde La batería se deteriora cada vez que se carga. Cargando la batería sólo cuando está completamente descargada reducirá...
  • Page 22: Almacenamiento De La Batería

    ESPAÑOL Recomendaciones importantes sobre la batería 2. Almacenamiento de la batería Si la batería no se va a usar durante un periodo prolongado de tiempo (un mes o más), y para mantener el buen rendimiento de la misma, cargue o descargue (uso) la batería hasta que el nivel de la energía restante se encuentre entre el 30% y el 40%, y a continuación retírela del ordenador y guárdela en un lugar fresco y seco Si la batería se deja conectada a la unidad, se descargará...
  • Page 23 ESPAÑOL Recomendaciones importantes sobre la batería 3. Uso eficiente de la batería Deje el ordenador apagado cuando no lo use Ajuste (atenúe) el brillo del monitor LCD pulsando las teclas Fn + F1 Al pulsar las teclas Fn + F1 disminuirá el brillo, y se reducirá por tanto el consumo de energía. Antes de alejarse de su ordenador, pulse las teclas Fn + F7 (espera) o Fn + F10 (hibernación) para poner su ordenador en el modo de espera o hibernación Al pulsar estas combinaciones de teclas, su ordenador se pondrá...
  • Page 24 ESPAÑOL Recomendaciones importantes sobre la batería 4. Cosas a tener en cuenta al usar la batería Utilice o guarde la batería en el margen de temperaturas de 10°C a 30°C No deje que la batería quede expuesta durante largos periodos de tiempo a la luz directa del sol, o bien en un lugar caliente (en el interior de un coche cerrado estacionado al sol, por ejemplo), o bien en un lugar frío.
  • Page 25 ESPAÑOL Recomendaciones importantes sobre la batería 5. Actualización de la batería La batería dispone de una función para medir, guardar y averiguar la carga de la batería. Para utilizar esta función apropiadamente con el fin de visualizar con exactitud la carga restante de la batería, es necesario que la misma se encuentre completamente cargada (al 100%), luego se descargue a fondo y finalmente vuelva a cargarse completamente.
