The m aster disconnect solenoid will carry 110 am ps of continuous load. Som e vehicles' alternators are capable of producing a
higher am perage output. In m ost vehicles this will happen only for a very short period of tim e and will not affect this product.
The receiver "m ust" be m ounted "inside" the vehicle to avoid m oisture from entering the unit. Use the sm all m ounting tabs located on
the side of the unit or double sided tape to m ount the unit. DO NOT DRILL ANY HOLES IN THE CASING TO MOUNT THE
UNIT!
The electric m aster disconnect solenoid should be m ounted as close as possible to the path of the
positive battery cable running between the battery and starter solenoid.
The disconnect solenoid is W ATER RESISTANT not
the solenoid, choose a location carefully to lim it exposure as m uch as possible. The solenoid m ust be
m ounted with the black solenoid internal shaft cover facing down.
NOTE: Running from one of the "sm all" wire studs on the solenoid is a short black jum per wire. This
wire as well as the solenoid itself m ust be connected/m ounted to a GOOD GROUND source. Failure to
do so will prevent the unit from operating.
The receiver is prewired. Connect the BLACK wire to a good ground. Connect the two halves of the two way connector with red and
brown wires together. Connect the RED wire to hot all the tim e (battery feed) "fused" 10 am p power source. Connect the BROW N
wire to the other sm all "em pty" term inal on the solenoid NOTE: The receiver will draw approxim ately 10.5 nA (nano am ps) in
stand by m ode.
NOTE: IT W ILL BE NECESSARY TO OPEN THE REMOTE AND REMOVE THE PAPER TAB BETW EEN THE
BATTERY AND THE CONTACTS BEFORE USE. THIS IS TO SAVE BATTERY LIFE OF REMOTE.

Receiver mounting

Solenoid m ounting
W ATER PROOF. For this reason, when m ounting

Receiver wiring

Over
